3 Phase Transformer Diagram: Windings, Vector Groups, and Connection Diagrams for Delta and Wye Transformers — interactive diagram. Open it in the editor to customise components and wiring.

This is a free printable 3 phase transformer diagram: download the diagram as SVG or open it and print to paper or PDF.

A 3-phase transformer diagram shows the physical winding connections, terminal labelling, and vector group notation that define voltage ratio, phase displacement, and neutral availability for power distribution systems.

A three-phase transformer steps voltage up or down across all three phases simultaneously. In a single three-phase unit, all three phase windings share a common magnetic core, producing a compact and efficient design compared to a bank of three single-phase transformers. The way each winding is connected — either in delta (triangle, Δ) or wye (star, Y) configuration — determines the voltage relationships between phases and the availability of a neutral point.

In a delta connection, the three winding ends connect head-to-tail forming a closed triangle. There is no neutral point. The phase voltage across each winding equals the line-to-line voltage. Delta connections handle third-harmonic currents well and are preferred on the high-voltage primary of distribution transformers where a neutral is not needed.

In a wye (star) connection, one end of each of the three windings connects to a common neutral point (the star centre), and the other end connects to a line terminal. The phase voltage across each winding is the line-to-line voltage divided by √3 (approximately 57.7% of line voltage). A wye secondary provides a neutral terminal, enabling single-phase loads to be connected line-to-neutral, which makes it the standard secondary connection for distribution systems supplying 400 V three-phase four-wire networks (230 V phase-to-neutral).

Vector group notation describes both the winding configurations and the phase displacement between primary and secondary voltages. The notation uses letter codes — D for delta, Y for wye (star), Z for zigzag — and a clock number from 0 to 11 representing the phase angle displacement in 30° steps between the primary and secondary phase voltages. The primary winding is denoted by an uppercase letter; the secondary by a lowercase letter. A lowercase 'n' indicates the neutral is brought out.

The most common distribution transformer vector group is Dyn11: primary winding in delta (D), secondary winding in wye (y) with neutral brought out (n), and a phase displacement of 11 × 30° = 330° (equivalent to –30°). This is the standard group for 11 kV to 400 V distribution transformers in IEC-based countries. The 30° phase displacement inherent in Dyn11 transformers is why paralleling transformers from different vector groups requires phase-shift correction.

Other common groups include YNyn0 (used for LV–LV isolation transformers where in-phase connection is required) and Dyn1 (–30° displacement, used in some regions). Transformers of different vector groups cannot be directly paralleled without phase compensation.

How to wire 3 phase transformer diagram

Determine the required voltage ratio, vector group, and neutral requirement State the primary and secondary voltages (e.g., 11 kV to 400 V), whether a neutral is needed on the secondary (required for four-wire three-phase distribution), the required vector group (Dyn11 for standard distribution), and the apparent power rating in kVA.
Draw the primary winding connection For a delta (D) primary: draw three winding symbols (two parallel lines indicating primary inductance) connected head-to-tail in a triangle. Label the line terminals A, B, C at each junction. For a wye (Y) primary: draw three windings with one end of each connected to a common neutral point N, and the other ends as line terminals A, B, C.
Draw the secondary winding connection For a Dyn11 transformer, draw the secondary as a wye (star): three windings with tails connected to a common point labelled 'n' (neutral terminal), and heads connected to line terminals a, b, c. The secondary neutral 'n' is brought out as a terminal.
Show the phase displacement using a phasor diagram Draw the primary phasors VA, VB, VC at 120° spacing. Draw the secondary phasors Va, Vb, Vc displaced by the vector group angle. For Dyn11, the secondary phasors are displaced 330° (or –30°) from the primary. Va is at the 11 o'clock position relative to VA at 12 o'clock.
Label all terminals and indicate the tap changer position Label all high-voltage and low-voltage terminals per IEC 60076 (or the applicable national standard). Show the off-circuit or on-load tap changer (OLTC) on the HV winding, with the tap positions and corresponding voltage ratios. Include the rated tap (principal tap) and the ±step range.
Add the earthing arrangements Show the secondary neutral terminal connection to the earthing system. In IEC distribution systems, the transformer neutral is solidly earthed (connected to the earth electrode system). Show the HV cable screens and transformer tank earthing connections.

Specifications

Standard vector group for 11 kV / 400 V distribution	Dyn11 (IEC 60076 notation)
Phase displacement — Dyn11	330° (or equivalently, secondary lags primary by 30°)
LV phase-to-neutral voltage (400 V system, Dyn11)	230 V
LV line-to-line voltage (400 V system)	400 V
Ratio of line voltage to phase voltage (wye connection)	√3 ≈ 1.732
Applicable standard	IEC 60076 (Power transformers)
Typical off-circuit tap range	±2 × 2.5% or ±5% of rated HV voltage

Safety warnings

All work on high-voltage transformer installations must be performed by licensed electrical engineers and high-voltage cable jointers with appropriate authorisation. High-voltage equipment is lethal. Strict permit-to-work and isolation procedures must be followed.
Transformer oil in oil-immersed units is a fire risk. Do not perform hot work (welding, cutting, grinding) near oil-filled transformer equipment without specific precautions and a fire permit.
Oil-filled transformers that have been in service may contain polychlorinated biphenyls (PCBs) in older units. PCB-contaminated oil is classified as a hazardous substance — handle and dispose of in accordance with applicable environmental regulations.
Before working on a de-energised transformer, verify both the HV and LV sides are isolated, locked, earthed, and proved dead. Induced voltages from adjacent live cables or busbars can be present even on an isolated transformer.
All transformer installations must comply with IEC 60076 (power transformers) and the applicable national installation and protection standards.

Tools needed

Insulation resistance tester (megohmmeter) — minimum 5 kV test voltage for HV equipment
Transformer ratio test set (TTR)
Winding resistance bridge
Phase rotation and vector group verification meter
Approved high-voltage voltage indicator and earthing sets
Oil sampling kit (for oil-filled units) and dielectric strength test equipment

Common mistakes

Attempting to parallel two transformers of different vector groups without verifying phase displacement, causing destructive circulating currents.
Connecting the LV neutral to earth at the transformer and also at remote distribution points, creating a TN-C-S system without proper design — this can cause N-PE faults and shock hazard.
Misidentifying transformer terminals by their physical position rather than by their labels, causing incorrect phase rotation or reversed polarity on the secondary.
Applying full voltage to a transformer that has been out of service for an extended period without first testing insulation resistance and performing a step-voltage energisation.
Ignoring tap changer position when calculating expected secondary voltage — a transformer with a ±2.5% × 4 tap changer at the −10% tap position will output 360 V rather than 400 V.

Troubleshooting

Secondary voltage is significantly different from expected on all three phases: Cause: Tap changer is not at the principal (rated) tap position, or incorrect voltage ratio transformer has been installed. Fix: Verify the tap changer position — check the tap changer indicator. Calculate expected secondary voltage at the current tap position using the nameplate tap voltage table. Adjust to the correct tap if required.
Unbalanced secondary voltages across the three phases: Cause: Internal winding turn-to-turn fault on one phase, or one HV input phase is missing (single phasing). Fix: Verify all three HV input voltages are balanced. Perform a transformer turns ratio (TTR) test on each phase to identify a winding fault. Remove from service and arrange specialist repair if a winding fault is confirmed.
Buchholz relay operates on a new transformer at first energisation: Cause: Air trapped in the oil during filling. Air bubbles rise through the oil and are caught by the Buchholz relay, triggering the gas alarm. Fix: This is a normal occurrence on first energisation. Reset the Buchholz relay gas alarm, operate the oil release valve to expel trapped air, and monitor for recurrence. Recurrence after the initial period indicates an internal arc or insulation fault requiring investigation.

Frequently asked questions

What does the vector group Dyn11 mean?

Dyn11 means: D — primary winding is delta connected; y — secondary winding is wye (star) connected; n — the neutral point of the secondary star is brought out as a terminal; 11 — the secondary phase voltage lags the primary by 11 × 30° = 330° (or equivalently leads by 30°). Dyn11 is the standard vector group for 11 kV to 400 V distribution transformers in IEC regions.

Why does a delta connection have no neutral point?

In a delta connection, the three windings form a closed triangle. All three winding connection points are line terminals (A, B, C). There is no fourth terminal connected to a common point, so no neutral is available. A delta connection is used on HV primaries where a neutral is not needed and on grounding transformers where third-harmonic currents must circulate freely.

Can two transformers with different vector groups be connected in parallel?

Not without phase-shift correction. Parallel transformers must have the same vector group (same phase displacement) so their output voltages are in phase and in phase sequence. Connecting a Dyn11 and a Dyn1 in parallel would produce 60° phase difference between outputs, causing large circulating currents that damage both transformers.

What is the advantage of a wye secondary with neutral (yn) over a delta secondary?

A wye secondary with neutral provides line-to-neutral voltage for single-phase loads — in a 400 V three-phase system, the neutral gives 230 V phase-to-neutral to each phase. Delta secondaries only provide line-to-line voltage (400 V) and cannot directly supply single-phase 230 V loads without additional transformers.

What are the standard HV terminal labels on a three-phase transformer?

IEC 60076 labels high-voltage terminals as A, B, C (with neutral terminal N if wye-connected) and low-voltage terminals as a, b, c (with neutral terminal n if wye-connected). Older European practice uses U, V, W for HV and u, v, w for LV. North American practice uses H1, H2, H3 for HV and X1, X2, X3 for LV, with H0/X0 for neutrals.
