A Victron wiring diagram shows how solar charge controllers, inverter-chargers, battery banks, and monitoring devices interconnect in an off-grid or hybrid energy system.

Victron Energy is a Dutch manufacturer of power conversion equipment widely used in off-grid solar, marine, caravan, vehicle, and backup power installations. Their product range covers MPPT solar charge controllers, inverter-chargers (MultiPlus and Quattro series), battery monitors (BMV series), lithium battery systems (Smart LiFePO4), and the VE.Bus / VE.Direct / VE.Can communication networks that allow system components to share data and be monitored via the Cerbo GX or similar gateway devices.

This page describes the general topology and wiring principles of Victron-based energy systems. Because product models, firmware versions, and system configurations vary considerably, the authoritative source for any specific installation is the Victron Professional documentation library (professional.victronenergy.com) and the wiring diagram resources published by Victron Energy. This content is illustrative and general; it is not a substitute for OEM documentation.

A typical off-grid system topology places a solar array connected to one or more MPPT charge controllers, which charge a battery bank. The battery bank also connects to an inverter-charger (e.g. MultiPlus-II) that converts DC battery power to AC for loads and can accept AC input from a generator or shore power to charge the battery. A battery monitor (BMV-712) or integrated BMS measures and communicates state of charge. A Cerbo GX communicates with all devices via VE.Bus (inverter-charger), VE.Direct (MPPT and BMV), or VE.Can (CAN-bus connected components).

Cable sizing is critical: the high DC currents in a 12 V, 24 V, or 48 V battery system require large cross-section cables and robust terminal connections. A 3000 W inverter at 24 V draws 125 A DC at full load — this requires at minimum 70 mm² cable for short runs and appropriate fusing at the battery terminal.

All Victron system wiring must be fused as close as possible to the positive battery terminal, with fuse or circuit breaker ratings matched to the cable size and not exceeding the component's input current rating.

How to wire victron wiring diagram

Consult the Victron wiring wizard and product documentation Before buying or building, use Victron's official Wiring Unlimited guide (freely available from Victron's website) and the Victron Wiring Wizard tool. These resources provide component-specific diagrams, cable sizing tables, and fusing recommendations for different system sizes and configurations. The Wiring Unlimited guide by Victron Energy is the primary engineering reference for their systems.
Determine system voltage and battery bank size Select 12 V, 24 V, or 48 V DC bus voltage based on maximum load power and practical cable run lengths. Calculate required battery capacity in Ah based on daily energy consumption, the number of days of autonomy required, and the maximum depth of discharge allowed for the battery chemistry (typically 50 % for lead-acid, 80–100 % for LiFePO4). Document this calculation before purchasing components.
Install the battery bank and main busbar Connect battery cells or modules in series and/or parallel to achieve the required voltage and capacity. For lithium batteries with a BMS, follow the BMS manufacturer's wiring sequence precisely — the BMS disconnects on fault and must be in the correct position in the circuit. Mount a positive and negative busbar or battery terminal block close to the battery to distribute power to multiple devices.
Install fuses at the battery terminals for each branch Every cable run leaving the battery positive must be fused within 500 mm of the battery terminal. Size each fuse to protect the cable, not the load. Use ANL fuses or MEGA fuses for high-current paths (inverter, main busbar), and blade or MIDI fuses for lower-current branches (charge controller, battery monitor, auxiliary loads). Never omit fusing or use an oversized fuse.
Connect the MPPT solar charge controller Connect the MPPT battery terminals (B+ and B−) to the battery bank via appropriately sized cable and a fuse at the battery terminal sized to the MPPT's maximum charge current. Connect the solar array input (PV+ and PV−) to the charge controller only after the battery connection is made — the MPPT controller requires a battery reference to safely operate. Do not reverse PV polarity.
Connect the inverter-charger Connect the MultiPlus or Quattro DC input terminals (B+ and B−) to the battery bank via heavy cable (sized for the inverter's maximum DC input current) and an appropriately rated fuse or battery isolation switch close to the battery. Connect AC output (shore power side and load side) per the MultiPlus installation manual — the AC wiring must comply with local electrical installation standards and in most jurisdictions requires a licensed electrician.
Connect monitoring devices and communication network Connect the BMV battery monitor shunt in the negative battery cable path (all battery bank negative conductors must pass through the shunt). Connect the Cerbo GX or Color Control GX to VE.Bus (RJ45 to inverter-charger), VE.Direct (to MPPT and BMV), and AC and DC power per the Cerbo installation manual. Configure each device via the Victron Connect app or GX device interface.

Specifications

Typical MPPT charge controller efficiency	> 98 % (varies by model; see Victron product datasheet)
MultiPlus-II inverter efficiency at half load	> 94 % (varies by model; see Victron product datasheet)
VE.Direct cable maximum length	10 m (standard; longer lengths may require RS485 repeater)
Recommended DC cable sizing reference	Victron Energy 'Wiring Unlimited' guide (freely downloadable)
Maximum distance from battery to fuse	500 mm (Victron and industry best practice)
LiFePO4 charge voltage (typical)	3.45–3.65 V per cell (14.2–14.6 V for 12 V 4-cell bank)
Lead-acid float voltage (12 V battery, typical)	13.5–13.8 V
Documentation source	professional.victronenergy.com — OEM manuals, wiring diagrams, Wiring Unlimited guide

Safety warnings

Battery banks — particularly large-capacity lithium and lead-acid systems — can deliver extremely high short-circuit currents (thousands of amps). A short circuit in unprotected wiring causes instant wire vaporisation, arc flash, and fire. Every cable leaving the battery positive terminal must be fused within 500 mm of that terminal. Never work on battery wiring without disconnecting the battery isolation switch and verifying that both busbars are de-energised.
LiFePO4 (lithium iron phosphate) batteries require a battery management system (BMS) and must never be overcharged, over-discharged, or charged at temperatures below 0 °C without appropriate low-temperature charge protection. Incorrect charging of lithium cells causes thermal runaway. Follow the battery manufacturer's installation and operating specifications exactly.
The AC wiring on inverter-charger output (MultiPlus, Quattro) operates at mains voltage (120 V or 230 V AC). This wiring must comply with the applicable electrical installation standard (BS 7671, NEC, IEC 60364, AS/NZS 3000) and must be installed by or under the supervision of a licensed electrician in most jurisdictions. The inverter's AC output can be live even when disconnected from grid or generator supply.
Solar PV array wiring is live whenever the panels are exposed to light — even under cloud cover, PV modules generate voltage. The array cannot be isolated by switching off the charge controller; it can only be de-energised by covering the panels. Always treat PV cable as live. DC arc faults in solar systems can be sustained and are very difficult to extinguish — use appropriate MC4 connectors rated for DC applications and route cables to prevent damage.
This page provides general wiring principles for educational reference. For any actual installation, follow the current version of Victron Energy's official documentation (professional.victronenergy.com), which is updated as products and firmware evolve. System design decisions — particularly battery sizing, cable sizing, and protection coordination — should be validated by a qualified system designer.

Tools needed

Digital multimeter (DC voltage up to 60 V, resistance, and continuity)
Clamp meter (DC current measurement capability for battery and charge controller circuits)
Crimping tool rated for large cable lugs (16–120 mm²)
Hydraulic lug crimper (for 50 mm² and above cable terminations)
Torque wrench (for busbar and battery terminal connections)
Victron Connect app (iOS or Android, for component configuration via Bluetooth)
Wire strippers for large gauge cable
Insulated gloves and safety glasses (for battery work)

Common mistakes

Fusing at the load end rather than the battery terminal — the fuse must protect the cable from the battery to the first branch point, not just the device. A fault in the cable between battery and a remote fuse is unprotected.
Running all negative conductors directly to the battery negative terminal rather than through the battery monitor shunt — any current that bypasses the shunt is invisible to the battery monitor and produces incorrect state-of-charge readings.
Connecting the solar PV input to the MPPT charge controller before connecting the battery — some MPPT controllers require the battery reference voltage present before accepting PV input, and connecting PV first can cause controller damage or startup errors.
Under-sizing DC cable between battery and inverter — at 12 V, a 3000 W inverter draws over 250 A DC. Using 16 mm² cable that is adequate for 20 A loads causes extreme voltage drop, efficiency loss, and overheating. DC cable sizing for inverters requires careful calculation using Wiring Unlimited tables.
Ignoring communication network wiring — a system where the Cerbo GX cannot communicate with the MPPT or inverter will not coordinate charging correctly and loses the ability to display state of charge, energy flows, and alarms. Use correctly rated RJ45/VE.Direct/VE.Can cables as specified.

Troubleshooting

MPPT charge controller not charging — shows no charge current despite sun on panels: Cause: Battery connection absent or fuse blown; PV voltage below the controller's minimum operating threshold; battery is already fully charged; or charge controller is in protection mode Fix: Measure PV open-circuit voltage at the controller input — it must be above the controller's minimum PV voltage for the connected battery voltage. Measure battery voltage at the controller battery terminal — not just at the battery itself, as a blown cable fuse shows voltage at the battery but not at the controller. Check fault flags via the Victron Connect app.
Inverter shuts down under load with a low-battery alarm: Cause: Battery bank voltage sags below the inverter's low-voltage cutoff under load, caused by undersized cable (excessive voltage drop), weak or partially discharged battery bank, or battery connections with high resistance Fix: Measure battery voltage at the battery terminal and at the inverter DC input simultaneously under load. A significant difference (more than 0.5 V) indicates excessive cable resistance or a loose terminal. Inspect and retighten all battery, busbar, and inverter terminal connections. If terminal connections are sound, the battery bank may have insufficient capacity or degraded cells.
Battery monitor shows incorrect state of charge: Cause: A current-carrying conductor bypasses the battery monitor shunt (connected directly to battery terminal rather than through the shunt), or the shunt settings (battery capacity, Peukert exponent) are incorrectly configured Fix: Trace all battery negative conductors and confirm every one passes through the shunt before reaching the battery negative terminal. Any direct battery negative connection that bypasses the shunt makes the monitor inaccurate. Reconfigure the BMV settings via Victron Connect to match the actual battery bank capacity and chemistry.

Frequently asked questions

What is VE.Bus and how does it connect Victron components?

VE.Bus is Victron's proprietary multi-master RS-485 based communication protocol used to connect MultiPlus and Quattro inverter-chargers to each other (for parallel or three-phase operation) and to the Cerbo GX or Color Control GX monitoring gateway. It uses RJ45 connectors and standard UTP cable. VE.Bus carries device configuration, status, and control signals — not power.

Should I use a 12 V, 24 V, or 48 V battery bank?

Higher DC bus voltage means lower current for the same power — 48 V systems carry one-quarter of the current of a 12 V system at the same load. This allows smaller cable cross-sections, lower resistive losses, and better efficiency. 48 V is preferred for systems above approximately 1500 W and is standard in most modern off-grid and hybrid installations. 12 V remains common in vehicles and small marine installations where 12 V loads are also present.

Where must the battery fuse be placed in a Victron system?

A fuse or circuit breaker must be installed as close as physically possible to the positive battery terminal — within 500 mm is the standard recommendation. This protects all downstream wiring from a fault that could otherwise cause a fire. Each device or cable run from the battery bus needs its own appropriately rated fuse, not a single large fuse for all branches.

Can a Victron MultiPlus charge a battery and power loads simultaneously?

Yes. The MultiPlus and Quattro inverter-chargers are bidirectional: when AC input (from grid or generator) is available, they charge the battery bank via an internal multi-stage charger while simultaneously passing AC power through to connected loads. When AC input is absent, they invert battery DC to AC for loads. The Quattro additionally has two separate AC inputs (grid and generator).

What is the correct fuse size for a Victron MPPT charge controller?

Fuse the MPPT charge controller's battery connection at the maximum charge current the controller is rated for, plus a safety margin — typically the next standard fuse size above the controller's rated output current. The Victron MPPT documentation specifies the maximum charge current and the recommended fuse rating for each model. The solar array input side should be fused per the array short-circuit current and the number of strings.
