A 3-wire outlet diagram shows the three conductors — line (hot), neutral, and equipment ground — that connect to the three terminals of a standard grounding-type power outlet and their roles in delivering safe AC power.

A modern residential and light-commercial power outlet (receptacle) has three electrical connections: the line or hot conductor, the neutral conductor, and the equipment grounding conductor. Each has a distinct electrical function, and confusing them is a wiring error that can result in shock, fire, or property damage.

The hot (line) conductor — black in North American practice, brown in IEC/European practice — connects to the smaller blade slot on the outlet (the right-hand vertical slot on a NEMA 5-series outlet). This conductor is energised at full circuit voltage relative to neutral and earth under normal conditions. Current flows out through this conductor to the connected appliance.

The neutral conductor — white in North American practice, blue in IEC/European practice — connects to the larger blade slot (the left-hand vertical slot on a NEMA 5-series outlet). This conductor completes the circuit by carrying current back to the source. In a correctly wired circuit, the neutral is held close to earth potential by the bonding at the service panel, but it is a current-carrying conductor and must be treated as potentially live if the circuit is not properly isolated.

The equipment grounding conductor — bare copper or green in North America, green-and-yellow striped in IEC practice — connects to the round or U-shaped ground pin at the bottom of the outlet. This conductor carries no current during normal operation. Its purpose is purely protective: if a fault develops in connected equipment causing a live conductor to contact the equipment chassis, the ground conductor provides a low-impedance path back to the panel, causing the breaker to trip and cutting the supply before a dangerous touch-voltage can persist.

The ground pin is longer on many outlet types so it makes contact first when a plug is inserted, grounding the appliance before the hot and neutral pins connect.

A 3-wire outlet diagram covers the three conductors present in a standard grounded circuit: the hot (black in North America), neutral (white), and ground (bare copper or green). The hot connects to the brass-coloured screw, neutral to the silver screw, and ground to the green screw on the receptacle. Understanding the correct terminal assignments prevents reversed polarity, which can energise exposed metal parts, and ensures GFCI devices operate properly. Use the free browser-based editor to draw or customise your outlet wiring diagram online without any download.

How to wire 3 wire outlet diagram

Isolate the circuit and verify dead Turn off the relevant circuit breaker. Use a non-contact voltage tester at the outlet to confirm no voltage is present on any terminal. Leave the breaker off and work safely.
Remove the old outlet (if replacing) Remove the cover plate and unscrew the outlet from the box. Pull the outlet forward carefully. Note the existing wire connections before disconnecting — photograph them if helpful.
Identify each conductor Identify the black (hot) wire, the white (neutral) wire, and the bare or green (ground) wire. If a cable has only two conductors with no ground (older wiring), do not install a standard grounding outlet unless local code alternatives (GFCI) are followed.
Connect the hot conductor Connect the black (hot) wire to the brass-coloured (gold) screw terminal on the outlet, or to the terminal labelled 'HOT' or 'LINE' if so marked. The brass terminal corresponds to the narrow blade slot. If using a back-stab connection, follow the outlet manufacturer's wire-gauge marking — screw terminal connections are more reliable and preferred.
Connect the neutral conductor Connect the white (neutral) wire to the silver-coloured screw terminal on the outlet. The silver terminal corresponds to the wide blade slot. If multiple white neutrals are joined in the box, the one returning to the panel connects here — not a switched return wire (which must be re-identified).
Connect the equipment ground Connect the bare copper or green insulated ground wire to the green screw terminal on the outlet. If multiple ground wires are present in the box, join them with a wire nut and use a pigtail to the outlet terminal.
Install, restore power, and test Fold the wires carefully into the box, secure the outlet with screws, and attach the cover plate. Restore power at the breaker. Use a socket tester to verify correct wiring (correct polarity, ground present). Confirm no voltage between neutral and ground pins — a voltage here indicates a neutral-ground reversal or a stray connection.

Specifications

Standard North American outlet (15 A)	NEMA 5-15R, 125 V, narrow hot slot 6.3 mm × 1.5 mm, wide neutral slot 6.3 mm × 1.8 mm
Standard North American outlet (20 A)	NEMA 5-20R, 125 V, accepts NEMA 5-15 plugs plus NEMA 5-20 plugs with T-slot neutral
UK standard outlet	BS 1363, 13 A, 230 V — fused plug with live (right), neutral (left), earth (top) slots
Australian/NZ standard outlet	AS/NZS 3112, 10 A or 15 A, 230 V — angled flat pin configuration
Hot terminal colour (North America)	Brass / gold screw
Neutral terminal colour (North America)	Silver screw
Ground terminal colour (universal)	Green screw

Safety warnings

Fixed electrical installation work must be performed by a licensed electrician and must comply with the applicable code — NEC/NFPA 70 (USA), BS 7671 (UK), AS/NZS 3000 (Australia/NZ), IEC 60364, or your regional equivalent. This diagram is illustrative and reference-only.
Always isolate the circuit at the distribution board and verify dead at the outlet using a calibrated non-contact voltage tester before touching any conductor.
Never connect the neutral and ground wires together at the outlet or anywhere in the branch circuit. They must only be bonded at the main service entrance panel. Connecting them together at an outlet causes all equipment grounded through that circuit to carry neutral current on their chassis.
Do not install a 3-prong (grounding) outlet without a connected equipment ground wire unless GFCI protection is provided and the outlet is labelled 'No Equipment Ground' as required by NEC 406.4(D).
Reversed polarity (hot and neutral swapped) may not be immediately apparent from appliance behaviour but is a code violation and a safety hazard. Always verify polarity with a socket tester after installation.

Tools needed

Non-contact voltage tester
Digital multimeter
Socket/outlet tester (plug-in type with indicator lights)
Wire strippers (14 AWG or 12 AWG as required)
Flathead and Phillips screwdrivers
Needle-nose pliers for forming wire hooks on screw terminals
Insulation resistance tester (for new cable runs)

Common mistakes

Connecting the hot wire to the neutral (silver) terminal and the neutral to the hot (brass) terminal — reversed polarity fault that a socket tester immediately identifies.
Using the back-stab (push-in) connections on a receptacle for aluminium wiring or without confirming the outlet's back-stab rating — screw terminals provide a more reliable and code-preferred connection.
Installing the outlet upside down with the ground hole at the top — while not a wiring error, it is non-standard; some authorities and codes specify orientation.
Sharing a neutral between two circuits in the same cable without ensuring both circuits are on opposite legs (a multi-wire branch circuit requires specific precautions and a handle-tied breaker).
Failing to pigtail the ground when multiple cables enter the box, connecting only one ground and relying on the outlet's grounding continuity for other devices in the box.
Not tightening the outlet screw terminals to a firm torque — loose connections cause arcing, heat, and eventual failure.

Troubleshooting

Socket tester shows 'open ground': Cause: The equipment ground wire is not connected, is broken, or the ground pin on the outlet is not making contact with the ground terminal Fix: Isolate the circuit. Pull out the outlet and verify the bare or green ground wire is secured to the green screw. Check the ground wire back through the circuit to the panel ground bus — use a continuity tester with the circuit isolated. If no ground wire is present, either run a new cable or install a GFCI outlet with the 'No Equipment Ground' label.
Socket tester shows 'reversed polarity': Cause: Hot (black) wire is connected to the neutral (silver) terminal and/or neutral (white) wire to the hot (brass) terminal Fix: Isolate the circuit. Pull out the outlet. Identify the hot (black) wire and connect it to the brass (smaller slot) screw. Connect the white neutral to the silver (larger slot) screw. Re-test.
Outlet has no power but circuit breaker has not tripped: Cause: Loose or broken connection at the outlet, a failed wire nut joint in the box, or a break in the cable feeding this outlet Fix: Isolate the circuit and pull the outlet out. Inspect all wire nut connections and screw terminals. Check for a broken conductor inside the cable sheath. If this outlet is daisy-chained from a previous outlet, check that outlet's connections as well — a break in the daisy-chain will kill all downstream outlets.

Frequently asked questions

What is the difference between the neutral and the ground in a 3-wire outlet?

The neutral is a current-carrying return conductor — current flows through it during normal operation. The ground carries zero current during normal operation; it only conducts during a fault event to trip the breaker. In a correctly installed system, the neutral and ground are bonded only at one point — the main service panel earthing terminal — and must not be connected together anywhere else in the branch circuit.

Is it dangerous to swap the hot and neutral wires at an outlet?

Yes. With hot and neutral reversed (called a 'reversed polarity' fault), the outlet appears to work correctly for most appliances. However, on appliances with a single-pole switch or fuse in the hot conductor — such as a lamp — the switch disconnects the neutral rather than the hot, leaving the socket energised. This creates a shock hazard when changing a lamp.

Can a 3-wire outlet be installed without a ground wire?

A grounding-type (3-slot) outlet should only be installed where a ground conductor is present and connected. Installing a grounding-type outlet without a connected ground conductor creates a false sense of safety. NEC 406.4(D) permits GFCI protection as an alternative where no ground conductor is available, but the outlet must then be labelled 'No Equipment Ground.'

Which slot is hot and which is neutral on a NEMA 5-15 outlet?

On a standard NEMA 5-15 (North American) outlet, the narrower vertical slot on the right-hand side (when facing the outlet) is the hot (live) slot. The wider vertical slot on the left is the neutral. The round hole at the bottom is the equipment ground. The asymmetric slot widths make the plug non-reversible, preventing incorrect hot/neutral connection at the appliance.

What does a socket tester (outlet tester) check in a 3-wire outlet?

A socket tester with indicator lights checks correct wiring, reversed polarity (hot and neutral swapped), open neutral, open ground, and hot-ground reversal. It does not detect a high-resistance ground or a neutral-ground swap at the panel. For definitive testing, use a digital multimeter to measure voltage between each pair of conductors.

How do you wire an outlet using a diagram?

Connect the black (hot) wire to the brass screw on the outlet, the white (neutral) wire to the silver screw, and the bare or green ground wire to the green screw. If the outlet is in a multi-outlet run (daisy-chained), use the back or side terminals to carry the circuit onward to the next receptacle. Always verify polarity with a plug-in tester after installation and before energising the circuit.
