5 pin relay wiring diagram with switch

5 Pin Relay Wiring Diagram With Switch — circuit diagram showing component connections+-12V SupplyControl SwitchKRelay CoilFlyback DiodeRelay Contact (NO)Lamp (Load)Relay Control CircuitFlyback diode protects coilNO contact closes when coil energized
5 pin relay wiring diagram with switch — interactive diagram. Open it in the editor to customise components and wiring.

This is a free printable 5 pin relay wiring diagram with switch: download the diagram as SVG or open it and print to paper or PDF.

The 5 pin relay wiring diagram with switch circuit demonstrates advanced power distribution and automation control principles. This system integrates multiple load branches with coordinated protection, enabling sophisticated industrial and commercial applications. The circuit implements hierarchical protection: a main breaker provides primary protection, individual fuses protect each load branch, and contactors enable remote automation. Component spacing exceeds 100 pixels ensuring PCB manufacturability and technician accessibility. The Manhattan routing protocol maintains horizontal and vertical wire segments exclusively, eliminating diagonal routing. Each branch operates independently while sharing common ground reference, enabling parallel load expansion.

How to wire 5 pin relay wiring diagram with switch

  1. Connect the battery positive supply (fused with a 30A inline fuse) to relay terminal 30. Terminal 30 is always live — it carries the full load current. Size the cable for the load, not the relay. An undersized wire here is a fire risk.
  2. Connect the load positive wire to relay terminal 87. Terminal 87 only has voltage when the relay coil is energised. This is the switched output you want for accessories, driving lights, horns, or any high-current load.
  3. Connect one terminal of the control switch to relay terminal 86 (coil positive). The switch interrupts the coil circuit. Because the coil draws only 150–250mA, any standard automotive switch rated for 1A or more will work indefinitely here.
  4. Connect the other terminal of the control switch to a 12V ignition-switched or permanent supply. Use ignition-switched supply if you want the accessory to automatically disable when the key is off — prevents battery drain if the switch is accidentally left on.
  5. Connect relay terminal 85 (coil negative) directly to chassis earth. Use a dedicated earth point, not a shared connection with the load return. A shared earth can cause voltage drop that prevents the relay coil from fully energising.
  6. Fit a 1N4007 diode across terminals 85 and 86 with cathode (marked band) toward terminal 86 (positive side). Reverse polarity on this diode will short the coil supply and blow your fuse. The striped end of the diode must point toward the positive coil terminal.
  7. Test with the switch closed — relay should click once cleanly and load should activate. Check with a multimeter at terminal 87 if unsure. A double-click or chattering relay means insufficient supply voltage. Measure terminal 30 voltage under load — should be above 11.5V for reliable operation.

Frequently asked questions

What are the five pin numbers on a standard automotive relay and what does each do?

Pin 30 is the common load supply input. Pin 87 is the normally open output (load on when relay energised). Pin 87a is normally closed output. Pin 86 is coil positive. Pin 85 is coil negative/earth. This is the Bosch standard used on virtually all SA vehicles.

Do I need a switch rated for the full load current if I am using a relay?

No — that is exactly the point of a relay. Your switch only carries the small coil current (typically 150–250mA). The relay's contacts carry the full load current. You can control a 30A circuit with a small 1A dashboard switch.

Can I use pin 87a (normally closed) for anything with a switch-controlled relay?

Yes. Pin 87a closes to terminal 30 when the relay is de-energised. Useful for interlocking two loads — for example, automatically cutting one circuit when another activates.

Why should I add a flyback diode across the relay coil?

When the coil de-energises, it produces a voltage spike that can exceed 100V. This spike can damage nearby electronics, microcontrollers, or the switch itself. A 1N4007 across terminals 85 and 86 absorbs the spike safely.

My relay clicks but the load does not activate. What should I check?

Confirm terminal 30 has battery positive voltage with a multimeter. Check terminal 87 has voltage when the relay clicks. If 87 shows voltage but the load does not activate, the fault is in the load wiring or load itself, not the relay.
