Delta-Wye Transformer Diagram
This is a free printable delta wye transformer diagram: download the diagram as SVG or open it and print to paper or PDF.
A delta-wye transformer diagram illustrates the Dyn configuration: delta-connected primary, wye-connected secondary with a grounded neutral, used for most utility step-down and industrial distribution applications.
The delta-wye (Δ-Y) transformer is the most common configuration in utility and industrial power distribution. The primary windings form a closed delta with no neutral connection, while the secondary windings are star-connected with all three winding ends joined at a neutral point that is then grounded.
The standard vector group notation is Dyn11. 'D' indicates a delta primary, 'y' indicates a wye (star) secondary, 'n' indicates the secondary neutral is brought out and earthed, and '11' indicates 30 degrees of phase advancement on the secondary relative to the primary (as on a clock face, where 12 is 0° and 11 is 330° = −30°, or equivalently +30° lead). This 30-degree phase shift is a fundamental consequence of the delta-wye transformation and must be accounted for when paralleling with other transformers.
The wye secondary provides a four-wire output (three phases plus neutral), making it directly suitable for mixed single-phase and three-phase loads. Phase-to-neutral voltage equals the phase-to-phase voltage divided by √3. For example, a 415 V phase-to-phase secondary delivers 240 V phase-to-neutral — the standard low-voltage system used throughout Europe, Africa, Australia, and large parts of Asia.
The delta primary prevents zero-sequence (earth-fault) currents from flowing back into the supply network. It also provides a circulating path for third-harmonic currents within the primary delta, keeping harmonics off the transmission line. The grounded wye secondary provides a clearly defined neutral reference, which simplifies ground-fault protection and allows earth-leakage circuit breakers (RCDs/GFCIs) to operate reliably.
For transformer installations feeding sensitive electronics, a screen (electrostatic shield) between primary and secondary windings reduces capacitively coupled noise. This is particularly relevant in facilities with variable-frequency drives or medical equipment.
Transformer impedance (%Z), typically 4–6 % for distribution units, controls fault current contribution and must be factored into the site's switchboard short-circuit ratings.
How to wire delta wye transformer diagram
- Identify primary delta terminals Locate the three primary terminals (H1, H2, H3 on a three-phase unit, or the A, B, C terminals of three single-phase units). Confirm the nameplate voltage and that the incoming supply voltage matches the primary rating.
- Connect the primary delta Link the three primary windings in a closed triangle: H1 of winding 1 to H2 of winding 3, H1 of winding 2 to H2 of winding 1, H1 of winding 3 to H2 of winding 2. Each junction connects to one phase of the incoming three-phase supply through overcurrent protection.
- Connect the secondary wye windings Join the X2 terminals (or equivalent winding ends) of all three secondary windings together at a common neutral point. This creates the star point. On a three-phase unit, this is an internal connection; on a bank of single-phase units, it must be made externally at a suitable terminal block.
- Ground the neutral Connect the neutral point to the system earth electrode via a neutral-to-earth link or solid grounding conductor, sized per the applicable code (NEC 250.28, BS 7671 Chapter 54, or IEC 60364-5-54). Record the earth electrode resistance after testing.
- Connect secondary line conductors Run phase conductors from the X1 terminals of each secondary winding (the free ends of the star) to the main distribution switchboard. Include the neutral conductor. Label conductors L1/L2/L3/N (or R/S/T/N per regional convention).
- Verify voltage ratios and phase rotation Before connecting any load, measure phase-to-phase and phase-to-neutral voltages on the secondary to confirm they match design values. Use a phase-rotation meter to verify the ABC sequence is correct for any connected motors.
- Megger insulation resistance and commission Perform insulation resistance tests on primary and secondary windings to earth and between windings (typically at 1 000 V DC for LV windings, higher for MV primaries). Record results. Commission only if values exceed minimum thresholds per manufacturer and applicable standard.
Specifications
| Vector group | Dyn11 (delta primary, wye secondary with neutral, 30-degree phase advancement) |
|---|---|
| Secondary configuration | Four-wire (3 phases + neutral), neutral solidly earthed |
| Phase-to-neutral voltage (415 V system) | 240 V (= 415 ÷ √3) |
| Phase-to-neutral voltage (208 V system) | 120 V (= 208 ÷ √3) |
| Phase displacement (secondary to primary) | 30 degrees advancement (Dyn11 clock notation) |
| Typical distribution transformer impedance | 4–6 % (nameplate %Z) |
| Cooling class (dry/oil) | AN/AF (dry-type) or ONAN/ONAF (oil-type) per IEC 60076-2 |
| Applicable standards | IEC 60076-1, NEC/NFPA 70, BS 7671, AS/NZS 3000, IEC 60364 |
Safety warnings
- Transformer primary and secondary terminals are energised at potentially lethal voltages. Always apply lockout/tagout (LOTO) to both primary and secondary supplies before performing any inspection, connection, or maintenance. Verify the transformer is de-energised with a CAT IV rated voltage tester.
- A 30-degree phase shift (Dyn11) means a Dyn11 transformer cannot be directly paralleled with a transformer of any other vector group. Incorrect paralleling causes severe fault currents that can destroy both transformers and connected equipment. Always confirm matching vector groups before paralleling.
- The transformer neutral must be solidly earthed at the point of supply per the applicable electrical code (NEC 250, BS 7671, IEC 60364). An unearthed neutral creates an undefined voltage reference and prevents earth-fault protection devices from operating correctly.
- This diagram is an illustrative reference only. Transformer installation, commissioning, and maintenance must be performed by suitably qualified and licensed electricians or electrical engineers in accordance with NEC/NFPA 70, BS 7671, AS/NZS 3000, IEC 60364, or the relevant national standard.
- Medium-voltage (MV) primary connections above 1 000 V require additional safety precautions including appropriate PPE for the arc flash incident energy level, per NFPA 70E or equivalent standard. An arc flash hazard analysis must be completed before working on MV equipment.
Tools needed
- Calibrated true-RMS voltmeter (CAT IV rated for primary voltage class)
- Phase-rotation meter
- Insulation resistance (megohm) tester (1 000 V DC for LV; 5 000 V DC for MV windings)
- Earth electrode resistance tester
- Clamp-type ammeter
- Torque wrench for terminal connections
- Lockout/tagout set
Common mistakes
- Connecting the supply to a primary with the wrong voltage tap selected — always confirm the primary tap position matches the supply voltage before energising.
- Failing to earth the secondary neutral, creating a floating neutral that causes phase-to-neutral voltages to become unequal under unbalanced loading.
- Paralleling a Dyn11 with a Dyn1 or any other vector group — always verify identical vector groups and matched per-unit impedances before paralleling.
- Underestimating transformer inrush current and selecting overcurrent protection that trips on every energisation — time-delay fuses or circuit breakers with appropriate inrush withstand are required.
- Installing the transformer without commissioning insulation resistance tests, missing internal winding faults that may not be apparent until the unit fails under load.
Troubleshooting
- Unbalanced secondary voltages under no load
- Cause: One secondary winding is open-circuited internally, or a phase connection is missing or has high resistance Fix: De-energise and lock out. Perform continuity and insulation resistance tests on each winding individually. Check all terminal connections for secure contact and correct torque. Contact transformer manufacturer if an internal winding fault is suspected.
- Neutral conductor carrying high current even with balanced three-phase loads
- Cause: Significant harmonic loading (e.g. switch-mode power supplies, VFDs) producing triplen harmonic currents that add in the neutral rather than cancelling Fix: Measure neutral current with a clamp meter and perform a harmonic analysis. Consider upsizing the neutral conductor to 200 % of phase conductor capacity. Evaluate harmonic filtering or a K-rated transformer if harmonic distortion is severe.
- Overheating transformer under normal load
- Cause: Transformer undersized for actual load, inadequate ventilation around the enclosure, or high harmonic distortion increasing core and copper losses Fix: Measure actual load current and compare to nameplate kVA. Verify cooling clearances per manufacturer data. Perform a load study and thermal survey. If harmonics are significant, compute the transformer K-factor and compare to the nameplate K-factor rating.
Frequently asked questions
What does Dyn11 mean on a transformer nameplate?
D = delta primary, y = wye (star) secondary, n = neutral brought out and earthed, 11 = 30 degrees phase advancement of the secondary voltage relative to the primary (using clock notation where 12 = 0°). This is the standard vector group for utility distribution transformers in many countries.
Why is the secondary neutral grounded in a Dyn transformer?
Grounding the wye neutral establishes a stable voltage reference for all three phases, enables single-phase loads to operate at phase-to-neutral voltage, and allows earth-fault protection devices (RCDs, earth-fault relays) to detect leakage currents and trip safely.
Can a Dyn11 transformer be paralleled with a Dyn1 transformer?
No. Dyn11 has a +30-degree secondary phase shift while Dyn1 has a −30-degree shift — a 60-degree difference. Paralleling transformers with different vector groups causes large circulating currents that can damage windings. Only transformers with identical vector groups and matched impedances should be paralleled.
What is the relationship between secondary line voltage and phase-to-neutral voltage?
In a balanced wye system, the phase-to-neutral voltage equals the phase-to-phase (line) voltage divided by √3 (approximately 1.732). On a 415 V system this gives 415 ÷ 1.732 ≈ 240 V phase-to-neutral. On a 208 V North American system it gives 208 ÷ 1.732 ≈ 120 V.
Why does a delta primary suppress harmonics?
Third-harmonic and triplen (multiples of 3) currents in a three-phase system are in phase with each other. The closed delta primary winding provides a closed loop in which these harmonic currents circulate, preventing them from propagating back into the upstream transmission network.
