Dryer Plug Wiring Diagram: NEMA 14-30 vs NEMA 10-30 — interactive diagram. Open it in the editor to customise components and wiring.

This is a free printable dryer plug wiring diagram: download the diagram as SVG or open it and print to paper or PDF.

A dryer plug wiring diagram covers the two North American standards: the 4-wire NEMA 14-30 (current code) and the legacy 3-wire NEMA 10-30, explaining conductor assignments and safe replacement procedures.

North American electric dryers operate on a 240 V AC split-phase supply derived from two 120 V legs of the residential panel. The dryer uses 240 V for the heating element and 120 V (one leg plus neutral) for the motor, controls, and timer.

NEMA 14-30 (4-wire, current NEC requirement): This is the configuration required by the National Electrical Code (NEC / NFPA 70) for new installations since 1996. The four conductors are: - Line 1 (L1): Hot — typically black, 120 V to neutral - Line 2 (L2): Hot — typically red, 120 V to neutral, 240 V to L1 - Neutral (N): White — provides the 120 V centre tap for motor and controls - Ground (G): Green or bare copper — safety earth, bonded to the appliance chassis and panel earth

The critical safety point: on a 4-wire installation, the appliance chassis is bonded to the separate equipment ground conductor, not to neutral. This means a broken neutral conductor does not energise the appliance chassis.

NEMA 10-30 (3-wire, legacy): This configuration — two hots and a neutral, no separate ground — was permitted by the NEC under an exception for existing branch circuits prior to the 1996 revision. The appliance chassis was bonded to neutral in this arrangement, which is inherently less safe because a break in the neutral conductor places the chassis at full line voltage.

The NEC still permits NEMA 10-30 for existing installed circuits under the exception at 250.140 — but new dryer circuits must be NEMA 14-30. Converting an existing 10-30 outlet to 14-30 requires running a new 4-wire circuit from the panel and replacing the outlet, cord, and removing the neutral-to-chassis bonding strap inside the dryer.

The 14-30 is rated 30 A at 125/250 V; wire size is 10 AWG copper for the circuit conductors.

Maytag dryers follow the same NEC-compliant wiring as other residential electric dryers, but the precise terminal block layout and cord entry point can vary between model generations. Modern Maytag dryers ship from the factory set up for a 4-wire cord (two hots, one neutral, one ground on separate terminals), while older homes may still have 3-wire 240 V circuits. Switching between the two configurations requires repositioning or removing a ground strap on the terminal block. You can sketch and annotate your dryer's wiring free online at circuitdiagrammaker.com.

How to wire dryer plug wiring diagram

Turn off power at the panel and verify dead Switch off the 2-pole 30 A breaker for the dryer circuit. Lock out or tag the breaker. Use a calibrated non-contact voltage tester or two-pole voltage indicator to verify the outlet is dead — test between both hots, between each hot and neutral, and between each hot and ground. Do not proceed until all readings are zero.
Identify the conductors in the new cable (NEMA 14-30) In a 10/3 with ground NM cable: Black = Line 1 (L1), Red = Line 2 (L2), White = Neutral, Bare or Green = Equipment Ground. In conduit wiring, conductors may be re-identified — always use black and red for the hot conductors and white for neutral. Never use white as a hot conductor in a dryer circuit without re-identification tape.
Connect conductors to the NEMA 14-30R receptacle The NEMA 14-30R receptacle has four terminals. Locate the terminal labels: the two hot (L1, L2) terminals are typically the two brass-coloured side terminals; the neutral (N) terminal is the silver-coloured terminal; the ground (G) is the green screw. Connect: Black to L1, Red to L2, White to N, Ground conductor to G. Tighten terminals to the receptacle manufacturer's torque specification.
Connect the dryer cord to the dryer terminal block Remove the dryer's access panel to the terminal block (typically at the rear lower section). The terminal block has three or four positions: L1, L2, Neutral, and Ground. For 4-wire NEMA 14-30: Black to L1, Red (or other hot) to L2, White to Neutral, Green or bare to Ground. Verify the neutral-to-chassis bonding strap is REMOVED — it is typically a green wire or metal strap between the neutral terminal and the chassis. Failure to remove it defeats the purpose of the 4-wire installation.
For NEMA 10-30 (existing circuit only): install bonding strap If connecting to a legacy NEMA 10-30 3-wire outlet: connect Black to L1, the other hot to L2, White to Neutral, and ensure the neutral-to-chassis bonding strap INSIDE the dryer IS installed and making firm contact. This strap provides the chassis ground through the neutral conductor in the absence of a separate ground. This arrangement is only permitted on existing, already-installed 10-30 circuits under NEC 250.140 exception.
Restore power and test Restore the 30 A breaker. Use a receptacle tester designed for 240 V NEMA 14-30 outlets to verify correct wiring polarity and ground presence. Start a dryer cycle and confirm both the heating element (requiring full 240 V) and the drum motor (requiring 120 V) operate correctly. A drum that turns but does not heat indicates an open in one hot leg.

Specifications

NEMA 14-30 rating	30 A, 125/250 V AC; 4-wire (L1, L2, Neutral, Ground)
NEMA 10-30 rating (legacy)	30 A, 125/250 V AC; 3-wire (L1, L2, Neutral/Ground combined)
Required conductor size (copper)	10 AWG for 30 A circuit conductors
Circuit breaker	2-pole, 30 A (double-pole for 240 V)
Dryer supply voltage	240 V AC (heating element); 120 V AC (motor, controls, timer)
Heating element power (typical residential dryer)	4,000–6,000 W at 240 V AC
Applicable standard	NEC / NFPA 70, Article 220 (branch circuits) and 250.140 (equipment grounding for ranges and dryers)
Maximum cord length (NEC)	2 m (6 ft) per NEC 422.16(B)(1) for new installations

Safety warnings

This diagram is for reference and educational purposes only. Dryer circuit installation and modification must be performed by a licensed electrician in accordance with the National Electrical Code (NEC / NFPA 70) and local amendments. Permits and inspections are typically required for new circuit installations. Contact your local authority having jurisdiction (AHJ) before commencing work.
Always turn off the 2-pole 30 A breaker and verify the circuit is dead with a calibrated voltage tester before touching any wiring. A dryer circuit operates at 240 V AC — contact with energised conductors at this voltage is likely to be fatal.
For NEMA 14-30 (4-wire) installations: the neutral-to-chassis bonding strap inside the dryer MUST be removed. Leaving it in place on a 4-wire installation connects neutral to chassis, partially defeating the safety function of the separate equipment ground conductor.
For NEMA 10-30 (3-wire, existing circuits only): the neutral-to-chassis bonding strap MUST be installed. Running a 4-wire dryer on a 3-wire circuit without the bonding strap leaves the chassis ungrounded.
Do not use 12 AWG wire for a 30 A dryer circuit. 12 AWG is rated only to 20 A under NEC Table 310.12. Using undersized conductors creates a fire risk. Always use 10 AWG copper or consult the NEC for aluminium conductor equivalents.

Tools needed

Non-contact voltage tester and two-pole voltage indicator (for dead verification at 240 V)
240 V receptacle tester (NEMA 14-30 compatible) for polarity and ground verification
Insulated screwdrivers (flat-blade, rated for the terminal screw sizes on the receptacle and dryer terminal block)
Wire strippers rated to 10 AWG
Lineman's pliers or combination pliers
Torque screwdriver (set to receptacle manufacturer's specification — typically 20 in-lb for 30 A terminals)
Lockout/tagout lock and tag for circuit breaker
Flashlight or headlamp for work behind appliance

Common mistakes

Leaving the neutral-to-chassis bonding strap installed when converting from NEMA 10-30 to NEMA 14-30, partially defeating the safety improvement of the 4-wire installation.
Using 12 AWG wire on a 30 A circuit, creating an overloaded conductor that will overheat under full dryer load without tripping the breaker.
Connecting both hot conductors to the same leg at the panel (both to L1 instead of L1 and L2), resulting in 0 V between the two hots rather than 240 V — the heating element will not operate and the dryer motor may draw excessive current.
Reversing neutral and ground at the receptacle — on a NEMA 14-30 installation these conductors are at different potentials under normal operation and must not be interchanged.
Failing to use a proper strain relief on the dryer cord at the chassis entry, allowing the cord to be pulled and eventually breaking the terminal connections inside the dryer.
Installing the wrong receptacle type — NEMA 14-30 and NEMA 6-30 look similar but are wired differently. Verify the receptacle part number before installation.

Troubleshooting

Dryer drum turns but there is no heat: Cause: One hot leg (L1 or L2) is not reaching the heating element. This can be caused by a blown fuse inside the dryer, a failed heating element, a faulty thermal fuse, or an open circuit in one hot leg of the supply Fix: Check dryer internal fuses and thermal fuse (common failure point on dryers — thermal fuse is a one-shot device that does not reset). Measure voltage between L1 and L2 at the dryer terminal block — should read approximately 240 V. If one hot leg reads 0 V at the terminal block, the fault is in the supply circuit or the dryer cord.
Breaker trips immediately when dryer is started: Cause: Short circuit in the dryer (wiring fault or failed component) or an overloaded circuit with insufficient conductor size Fix: Disconnect the dryer cord from the outlet and reset the breaker. If the breaker holds with the dryer unplugged, the fault is internal to the appliance. If the breaker still trips with the dryer unplugged, the fault is in the circuit wiring or receptacle. Inspect for damaged insulation, pinched conductors, or a failed receptacle.
Mild electric shock felt when touching the dryer chassis: Cause: On a 4-wire installation: the equipment ground conductor is open (not connected at the receptacle, at the panel, or broken in the cable). On a 3-wire installation: the neutral-to-chassis bonding strap is missing or the neutral is open Fix: Immediately stop using the appliance. Verify the equipment ground path with an ohmmeter between the dryer chassis and the panel earth bus. An open ground reading requires tracing and repairing the break before the appliance is used again.

Frequently asked questions

Can I convert my NEMA 10-30 dryer outlet to NEMA 14-30?

Yes, but it requires running a new 4-wire circuit (10 AWG, 4-conductor cable) from the panel to the outlet. The existing 3-wire cable cannot be reused. A licensed electrician should perform this work. Inside the dryer, the neutral-to-chassis bonding strap (a green or bare wire between the neutral terminal and chassis) must be removed after converting to a 4-wire supply.

What gauge wire is required for a dryer circuit?

A 30 A dryer circuit requires 10 AWG copper conductors (or 8 AWG aluminium, though copper is preferred for residential). The circuit uses a 2-pole 30 A breaker. For a 4-wire NEMA 14-30 circuit, the cable is 10/3 with ground: two hots (black and red), one neutral (white), one ground (green or bare). Do not use 12 AWG — it is rated only to 20 A.

Why does the older NEMA 10-30 3-wire dryer connection bond neutral to the chassis?

On a 10-30 installation, the neutral conductor serves double duty as both the current return for the 120 V circuits within the dryer and as the equipment ground. This was an accepted compromise before separate equipment grounding of appliances became mandatory. The risk is that a broken neutral conductor leaves the chassis floating at an indeterminate voltage — potentially full line voltage — creating a shock hazard.

Can I use a NEMA 14-30 dryer on a NEMA 10-30 outlet?

Yes, using a 14-30P to 10-30R adapter cord, but only if the existing outlet is on a correctly installed 3-wire circuit and you reinstall the neutral-to-chassis bonding strap inside the dryer (since the separate ground conductor is no longer present). This reinstates the 10-30 wiring arrangement and carries the associated risk of that configuration. NEC 250.140 permits this as an exception for existing circuits only.

Is it safe to use aluminium wiring for a dryer circuit?

Aluminium wiring is permitted for dryer circuits (and is commonly used for range circuits) but requires aluminium-rated receptacles, lugs, and outlets. Aluminium expands and contracts more than copper under load, requiring anti-oxidant compound at connections and periodic inspection for loose terminals. For residential dryer circuits, most electricians prefer copper for simplicity and long-term reliability.

How do you wire a Maytag dryer plug — 3-wire versus 4-wire?

On a Maytag electric dryer terminal block you will find three screw terminals: the two outer terminals accept the two 120 V hot legs (black and red), and the centre terminal accepts the neutral (white). For a 4-wire installation, the bare or green ground wire connects to the separate green ground screw and the neutral strap between the neutral terminal and the dryer chassis is removed. For a 3-wire installation (older outlets with no separate ground), the neutral and ground are bonded at the terminal block by leaving the ground strap in place and connecting the white cord wire to the centre terminal. Always confirm local code and manufacturer instructions before wiring.
