Lamp Diagram: Circuit, Components and Wiring Explained — interactive diagram. Open it in the editor to customise components and wiring.

This is a free printable lamp diagram: download the diagram as SVG or open it and print to paper or PDF.

A lamp diagram illustrates the electrical circuit connecting a light source to its supply, switch, and protective earth — covering incandescent, fluorescent, and LED lamp configurations.

At its most fundamental, a lamp circuit consists of three elements: a power source, a switching device, and a light-emitting load. The switch interrupts the live conductor feeding the lamp; closing the switch completes the circuit, current flows through the lamp element or driver, and light is produced.

Incandescent lamps: The load is a tungsten filament that heats to approximately 2,700 K, producing light by incandescence. The filament has a cold resistance far lower than its operating resistance (a 60 W, 230 V lamp has a cold resistance of roughly 50 Ω but an operating resistance of around 880 Ω). This means incandescent lamps draw a large inrush current at switch-on — typically 10–15 times the steady-state current for a few milliseconds. Switch contacts and dimmers must be rated to handle this inrush.

Fluorescent lamps: A low-pressure mercury vapour discharge lamp. Starting requires a ballast to limit current and (in older designs) a starter to briefly interrupt current and cause the electrodes to preheat. Electronic ballasts have replaced magnetic ballasts in most modern installations, providing soft-start, eliminating flicker, and operating at high frequency (>20 kHz) rather than at 50/60 Hz mains frequency.

LED lamps: The load is one or more light-emitting diodes. LEDs are current-controlled devices — they require a driver (a constant-current SMPS) to regulate current regardless of supply voltage variation. Mains-voltage LED lamps contain an integrated driver within the lamp body. The driver is the component that typically fails rather than the LED array itself.

All lamp circuits in fixed wiring installations must include protective earth conductors to any metal parts of the fitting. The switch always interrupts the live conductor, never the neutral — this ensures the lamp terminal is de-energised when switched off, allowing safe lamp replacement.

How to wire lamp diagram

Identify the lamp circuit type Determine whether the installation uses incandescent/halogen, fluorescent (magnetic or electronic ballast), or LED (integrated driver or separate driver). The wiring diagram and component selection differ significantly between these types. Note the supply voltage, frequency, and any dimming requirements.
Isolate the circuit and verify dead Switch off the circuit breaker supplying the lighting circuit. Verify dead at the fitting using a calibrated non-contact voltage tester before removing any cover or touching wiring. Do not rely on the wall switch alone — the COM terminal of the switch remains live even when the switch is off.
Connect the live (switched) conductor to the lamp terminal The conductor that becomes live only when the switch is closed (the switched live) connects to the lamp positive or live terminal. In a pendant rose, this is the terminal marked L or Live on the lamp block. This conductor is brown (current UK/EU convention) or re-identified from blue with brown sleeving where a switch cable is used.
Connect the neutral conductor The neutral conductor connects to the neutral terminal of the fitting (marked N or Neutral). In a loop-in installation at the ceiling rose, the neutral connects to the neutral terminal block and also loops through to subsequent fittings. The neutral is blue in current UK/EU wiring, black in older UK wiring, and white in North American wiring.
Connect the protective earth conductor Connect the earth conductor (green/yellow sleeved) to the earth terminal of the fitting or the back plate. If the lamp body is entirely non-conductive plastic, no earth connection to the lamp itself is required — but the ceiling rose or mounting base still requires earth if it has metal parts. Verify earth continuity after assembly.
Install the lamp and restore power Insert the lamp or LED module. For LED panels or fittings with external drivers, ensure the driver output is connected to the LED array as per the driver wiring diagram (polarity matters for DC LED drivers — incorrect polarity will prevent illumination or damage the LED array). Restore power and test by operating the switch.

Specifications

Typical LED lamp power (GLS replacement)	5–10 W (equivalent to 40–75 W incandescent)
Typical LED lamp lumen output	450–1000 lm (60 W equivalent: ~800 lm)
LED lamp colour temperature range	2700 K (warm white) to 6500 K (daylight)
Lamp holder bayonet cap rating (standard BC22)	6 A, 250 V; maximum lamp power as marked on holder
Pendant flex current rating (0.5 mm²)	3 A (suitable for lamps up to 690 W at 230 V — far exceeds LED loads)
LED driver efficiency (typical)	> 80% (better quality drivers > 90%)
LED lamp rated life (typical)	15,000–25,000 hours (L70, i.e. to 70% of initial lumen output)
Applicable standards	IEC 60598 (luminaires), IEC 60630 (lamp caps and holders), BS 7671 (fixed wiring, UK)

Safety warnings

This diagram is for reference and educational purposes only. Wiring of lamp fittings in fixed installations must comply with applicable regulations: NEC / NFPA 70 (USA), BS 7671 (UK), AS/NZS 3000 (Australia/New Zealand), IEC 60364 (international). Work by a licensed electrician is required in most jurisdictions for fixed wiring.
Always isolate the circuit at the consumer unit and verify dead before replacing a lamp fitting or accessing lamp terminals. Even a switched-off lamp switch leaves the COM terminal at live potential — the lamp holder is only safe to touch when the circuit is isolated at the panel.
Do not exceed the maximum wattage rating marked on the lamp holder or fitting. A 100 W incandescent lamp in a holder rated for 60 W maximum will overheat the holder and surrounding wiring insulation, creating a fire risk. LED lamps typically produce far less heat than their equivalent lumen incandescent and are less likely to overheat a holder — but the rated maximum still applies.
Lamp replacement in bathroom zones 1 and 2 must use fittings with the appropriate IP rating (minimum IP44 in zone 2, IP65 or better in zone 1 in the UK under BS 7671). Ordinary light fittings without appropriate ingress protection must not be installed in bathroom zones.
Halogen lamps must not be touched with bare skin — oils from skin contaminate the quartz envelope and cause thermal stress points that can shorten lamp life dramatically and in extreme cases cause the envelope to shatter. Handle halogen capsule lamps with a clean cloth or the packaging.

Tools needed

Non-contact voltage tester for dead verification
Insulated screwdrivers (flat and cross-head, VDE rated)
Wire strippers for 0.5 mm² flex and 1.0 mm² T&E cable
Continuity tester or multimeter
Long-nose pliers for terminal connections in confined roses
Stepladder or stable platform for ceiling work
PPE: safety glasses (risk of debris from drilling ceiling fixings)

Common mistakes

Wiring the switch to interrupt the neutral rather than the live conductor, leaving the lamp holder terminals permanently at mains potential even when the switch is off — a shock hazard during lamp replacement.
Using a non-dimmable LED lamp with a TRIAC dimmer switch, causing flicker, buzzing, and premature lamp failure.
Connecting the wrong polarity on a DC LED driver output — most LED panels will simply not illuminate, but some less protected designs can be damaged by reverse polarity.
Omitting the earth connection to metal lamp fittings — acceptable for Class II (double-insulated) fittings marked with the double square symbol, but mandatory for Class I metal fittings.
Using lamp holders with melted or discoloured terminals without investigation — thermal damage to a lamp holder indicates sustained overloading or a loose connection causing arcing, and the holder must be replaced and the cause investigated.
Installing a higher wattage replacement lamp than the fitting is rated for, particularly in enclosed or recessed fittings where heat cannot dissipate — this shortens LED driver life significantly even if it does not create an immediate hazard.

Troubleshooting

Lamp does not light when switch is operated: Cause: Failed lamp, open circuit in the switched live or neutral to the fitting, failed LED driver, or blown circuit breaker Fix: Replace the lamp with a known-good unit first — this is the simplest and most common cause. If the replacement lamp also fails to light, use a non-contact tester to confirm the switched live is present at the lamp holder terminal when the switch is on. If live is absent, trace the open circuit back through the switch to the consumer unit.
Lamp flickers intermittently when switched on: Cause: Loose connection in the lamp holder, ceiling rose, or switch terminal; incompatible LED/dimmer combination; or a lamp with a failing integrated driver Fix: Isolate the circuit. Check all terminal connections in the circuit path — loose connections are the most common cause of intermittent faults in lighting circuits. If connections are secure, test with a different lamp to rule out a failing lamp driver. If the circuit uses a dimmer, verify the LED lamp is rated as dimmable and compatible with the dimmer type.
Lamp is on but very dim, or appears to flash at low level: Cause: LED lamp with a poorly designed driver that does not fully discharge, powered by a capacitive or resistive load dimmer that maintains a small residual voltage, or a faulty neutral connection creating a floating neutral condition Fix: Check for a properly terminated neutral connection at the ceiling rose — a poor neutral contact can cause the circuit to complete through other connected loads at reduced voltage. If the dimmer is the cause, fit a load resistor (available for this purpose) across the lamp output, or replace the dimmer with a model specified for the lamp type.

Frequently asked questions

Why must the switch always interrupt the live conductor rather than the neutral?

If the neutral is interrupted and the live is connected permanently, the lamp holder and lamp terminals remain at live (mains) potential even when the light is off. Anyone replacing the lamp — who would reasonably expect it to be safe to touch — would receive a shock. Switching the live ensures that when the switch is open, no part of the lamp accessible to the user is energised.

What is the difference between a lamp ballast and a lamp driver?

A ballast is used with gas-discharge lamps (fluorescent, HID) to limit the arc current after the lamp strikes — without it, the arc would draw increasing current until it destroys the lamp or blows the fuse. A driver is used with LEDs to convert and regulate the supply into a constant current appropriate for the LED forward voltage and current. Both serve the purpose of controlling current to a non-linear load, but by different mechanisms.

Can I replace a fluorescent fitting with an LED tube directly?

It depends on the LED tube type. Type A LED tubes are designed to work with the existing fluorescent ballast — convenient but dependent on ballast compatibility. Type B (direct wire) LED tubes bypass the ballast entirely and connect directly to the mains — requires removing the ballast and rewiring, but eliminates the ballast as a future failure point. Type C LED tubes require a specific external LED driver. Mismatching types causes early failure or no operation.

Why do some LED bulbs flicker when connected to a dimmer switch?

Most mains dimmer switches work by phase-cutting the AC waveform (TRIAC or leading-edge dimming). LED drivers designed for non-dimmable operation do not respond smoothly to a chopped waveform — they may flicker, buzz, or fail to dim below a certain point. Dimmable LED lamps contain drivers designed to regulate output proportionally to the phase-cut input. Always verify both the dimmer and the LED lamp are rated for compatibility.

What does a lamp's colour temperature mean and how do I choose the right one?

Colour temperature is measured in Kelvin (K) and describes the perceived warmth or coolness of the light. 2700–3000 K is warm white, resembling incandescent light — suited to bedrooms and living areas. 4000 K is neutral or cool white — suited to kitchens and offices. 5000–6500 K is daylight — suited to workshops, task lighting, and areas where colour accuracy matters. The Kelvin rating has no bearing on power consumption or lumen output.
