5-Wire Trailer Wiring to 7-Pin Connector Diagram

5-Wire Trailer Wiring to 7-Pin Connector Diagram — interactive diagram. Open it in the editor to customise components and wiring.

This is a free printable 5 wire trailer wiring to 7 pin diagram: download the diagram as SVG or open it and print to paper or PDF.

Converting 5-wire trailer wiring to a 7-pin connector adds 12 V auxiliary power and a reverse light circuit, allowing a trailer originally wired for a 5-pin plug to connect to a tow vehicle with a 7-pin socket.

The conversion from a 5-wire to a 7-pin connector is a common upgrade for trailers that were originally fitted with a 5-pin or 5-flat connector when the tow vehicle is equipped with a 7-pin round or 7-flat socket.

WHY 7 PINS? The standard 7-pin connector adds two circuits that the 5-wire system lacks: - Pin 6 (or blue in some standards): Reverse/backup light feed — allows the trailer's rear-mounted reverse lights or camera to illuminate when the tow vehicle selects reverse gear. - Pin 7 (or black in some standards): Auxiliary 12 V battery charge — a constant or switched 12 V supply from the tow vehicle's battery to the trailer, used to charge a caravan house battery, power a refrigerator, or supply a breakaway battery.

NORTH AMERICAN 7-FLAT CONNECTOR PIN ASSIGNMENTS: 1. White: Ground/earth 2. Yellow: Left stop and turn 3. Red or Brown: Tail/running lights 4. Green: Right stop and turn 5. Blue: Electric trailer brakes 6. Brown or Black: Reverse/backup lights 7. Black or White (centre): Auxiliary 12 V power (battery charge)

Note: North American 7-flat and 7-round connectors exist, and pin assignments vary between manufacturers. Always refer to the specific connector standard for your vehicle.

EUROPEAN STANDARDS: ISO 11446 defines the 7-pin round N-type connector (standard lighting functions) and ISO 11449 defines the 13-pin connector (full caravan). A common European conversion uses a 7N (lighting) and 7S (auxiliary/brake) connector pair.

CONVERSION APPROACH: The existing 5 wires carry ground, tail, left, right, and brake (blue). To upgrade to 7-pin: extend the same wires to the new 7-pin connector matching their functions, then add two new wires — one from the tow vehicle's reverse light circuit to the new pin 6, and one from a fused 12 V ignition or constant supply to pin 7. If the trailer is not equipped with reverse lights or a battery, these pins remain wired at the connector but have no trailer-side termination.

How to wire 5 wire trailer wiring to 7 pin diagram

Identify the existing 5-wire functions and colours Before cutting or extending any wires, trace and document each of the five existing wire functions. Confirm which is ground (white), tail (brown), left (yellow), right (green), and brake (blue). Use a test light or multimeter to verify if colours are not clear.
Select the appropriate 7-pin connector standard Confirm whether your tow vehicle's socket is a 7-flat (North American) or 7-pin round (SAE J560 or ISO standard). The 7-flat and 7-round use the same circuits but are physically different and non-interchangeable without an adapter. Purchase a 7-pin plug that matches the tow vehicle socket.
Map the 5 existing wires to their corresponding 7-pin positions In the 7-pin connector, locate the positions for ground, tail, left, right, and brake — these match the existing 5-wire functions and connect to the same wires. The remaining two positions (reverse and auxiliary) will carry the new circuits.
Source the reverse light feed from the tow vehicle Run a new wire from the tow vehicle's reverse light circuit (available at the rear wiring harness or at the hitch wiring connector) to pin 6 of the 7-pin socket. Fuse this circuit at a value appropriate for any trailer reverse lamp load.
Source the 12 V auxiliary feed from the tow vehicle Run a new wire from a fused 12 V source (constant or ignition-switched, per your requirement) to pin 7 of the 7-pin socket. Size the wire and fuse for the expected trailer load. Many tow vehicles have a dedicated trailer charge output already available at the rear.
Extend new wiring along the trailer for reverse lights and auxiliary If the trailer is equipped with reverse lights or an auxiliary battery, run appropriately sized wires from the new 7-pin plug socket (trailer side) along the trailer frame to their respective endpoints. Secure wiring away from moving parts.
Test all seven circuits before towing Use a 7-pin trailer light tester or a helper to verify all circuits: running lights (brown/red), left stop/turn (yellow), right stop/turn (green), electric brakes (blue), reverse lights (brown/black pin 6), and auxiliary power (black pin 7). Confirm brake controller operation.

Specifications

North American 7-flat connector pin functions	Pin 1: ground (white); 2: tail/running; 3: left stop/turn; 4: right stop/turn; 5: electric brakes (blue); 6: reverse; 7: auxiliary 12 V
SAE J560 7-round connector pin functions	Pin 1: ground; 2: tail/running; 3: left stop/turn; 4: battery charge; 5: right stop/turn; 6: electric brakes; 7: auxiliary (see standard)
Auxiliary 12 V circuit (pin 7) fuse rating	15–30 A depending on load (caravan battery charging typically 20–30 A)
Reverse light circuit (pin 6) fuse rating	10–15 A
Wire sizes — existing 5 circuits	16 AWG lights; 14 AWG brakes and ground
Wire sizes — new circuits (reverse and auxiliary)	14–16 AWG reverse; 10–14 AWG auxiliary (size to load)

Safety warnings

Fuse both the reverse light and 12 V auxiliary circuits at the tow vehicle end. These are new wires that were not previously protected. An unfused auxiliary wire from the battery is a fire risk if it shorts along its length.
Never connect the auxiliary 12 V pin (pin 7) directly to the trailer brake magnets — this pin is for battery charging or auxiliary accessories, not brake power. The brake circuit uses pin 5 (blue).
Confirm the 12 V auxiliary is either fused at the battery or sourced from a circuit with appropriate overcurrent protection. Some tow vehicles have a dedicated trailer charge output that is already fused — check before adding a second fuse in series.
Verify brake function after any connector change. Replacing the connector physically can disturb the brake circuit wiring — confirm the brake controller activates trailer brakes before driving.
Do not use a 7-pin adapter on a 5-pin socket as a permanent solution for applications relying on the auxiliary power circuit — adapter pin contact reliability degrades with use, and a poor connection on the auxiliary circuit can cause battery undercharging in a caravan.

Tools needed

Multimeter and trailer light tester
Wire strippers (14–16 AWG)
Crimping tool and weatherproof connectors
Heat-shrink solder sleeves or heat-shrink tubing and soldering iron
Inline fuse holders
Cable clips and split-loom conduit
Drill (for cable clip mounting)
Dielectric grease

Common mistakes

Assuming the same pin number in a 7-flat connector matches the same function in a 7-round (SAE J560) connector — pin assignments differ between connector standards. Always refer to the specific standard for your connector type.
Connecting the 12 V auxiliary to an ignition-switched circuit when the application requires constant battery charging — a caravan battery will only charge when the engine is running, not while parked connected to shore power.
Not fusing the new wires added for the 7-pin upgrade — the existing 5 circuits were presumably fused, but the two new extension wires are a fire risk without protection.
Trusting colour codes alone for pin identification — wire colours in aftermarket harnesses and adapters do not always follow North American convention. Always verify pin function with a multimeter.
Leaving the connection area unweatherproofed — the point where existing 5-wire harness joins the new 2-wire extension is particularly vulnerable to moisture ingress if not properly sealed.

Troubleshooting

Reverse lights on trailer do not work after upgrade: Cause: The new reverse light wire is not connected to an active reverse signal on the tow vehicle, or the connection at the 7-pin plug pin 6 is open. Fix: With reverse gear selected, measure voltage at the vehicle's new wire source point — should be 12 V. Trace the wire through to pin 6 at the plug socket. If 12 V present at the socket pin 6 but trailer reverse light does not work, the fault is in the trailer's reverse lamp wiring.
Auxiliary battery in caravan not charging: Cause: Pin 7 is not connected to a functional 12 V source, the fuse has blown, or the caravan's internal battery charger circuit is faulty. Fix: Measure voltage at pin 7 of the vehicle socket with the engine running — should be battery/alternator voltage. If not, trace the supply wire and check the fuse. If voltage is present at the socket but the caravan battery does not charge, the fault is inside the caravan.
One of the original 5 circuits stopped working after the connector upgrade: Cause: A connection was disturbed during the upgrade — wire pulled out of a terminal or a splice opened. Fix: Identify the failed circuit by testing at the vehicle socket. Trace the relevant wire from the socket back through any junction points to the tow vehicle source. Re-terminate any disturbed connections.

Frequently asked questions

Do I need to run new wires along the trailer to upgrade from 5-pin to 7-pin?

The five existing functions (ground, tail, left, right, brake) reuse your current wiring. The two new functions (reverse lights and 12 V auxiliary) require new wires run from the plug to wherever those functions are needed on the trailer. If the trailer has no reverse lights or auxiliary battery, you only need to extend the harness at the plug end.

What is the auxiliary 12 V pin on a 7-pin connector used for?

It supplies 12 V DC from the tow vehicle to the trailer for charging a caravan house battery, powering an on-board refrigerator, or supplying a breakaway battery system. It is typically fused at the tow vehicle and may be either a constant feed (direct from battery) or a switched feed (ignition-on only), depending on the tow vehicle's wiring.

Can I use a plug adapter instead of rewiring?

Yes, a 5-to-7 pin adapter connects the matching 5 circuits and leaves the two new pins unused on the trailer side. This is a valid short-term solution if the trailer does not use the extra circuits. However, adapters add a connection point susceptible to corrosion and are less reliable than direct wiring for long-term use.

Will my brake controller still work after upgrading to a 7-pin connector?

Yes, the electric brake circuit (blue wire, pin 5 in North American 7-pin) is the same function in both connectors. The brake controller output connects to this pin in the 7-pin socket exactly as it did in the 5-pin socket. No changes to the brake controller or its wiring are required.

What wire size should I use for the new 12 V auxiliary circuit?

Size based on the expected load. For charging a caravan battery, 10–14 AWG is common (charging draw is typically 5–15 A). Fuse the circuit close to the tow vehicle battery at a value below the wire's ampacity. If only powering a breakaway battery or small accessory, 16 AWG is adequate.
