Distributor Diagram — interactive diagram. Open it in the editor to customise components and wiring.

This is a free printable distributor diagram: download the diagram as SVG or open it and print to paper or PDF.

Understand the internal wiring, cap terminal sequence, rotor direction, and ignition timing of a conventional and electronic distributor for petrol engine diagnosis and replacement.

The ignition distributor is the central component of a conventional petrol engine ignition system. Its primary function is to route high-voltage secondary ignition pulses from the ignition coil to each spark plug in the correct firing order and at the correct crankshaft position. Understanding the distributor's wiring and mechanical arrangement is essential for setting timing, diagnosing misfires, and replacing components.

The distributor cap has a central terminal that receives the high-voltage output from the coil secondary (via the coil wire), and one numbered terminal per cylinder arranged around its perimeter. The rotor, driven by the camshaft at half the crankshaft speed on a four-stroke engine, spins inside the cap. Its tip passes close to each terminal in sequence, allowing the high-voltage spark to arc across to the terminal and travel down the spark plug lead to the corresponding plug.

The firing order — the sequence in which cylinders fire — is an engine design specification and does not follow the physical numbering of cylinders. A common inline-four firing order is 1-3-4-2; a common V8 firing order is 1-8-4-3-6-5-7-2 (though this varies by manufacturer and engine family). Knowing the firing order, the direction of rotor rotation (viewed from above), and the position of the number-one cylinder terminal on the cap allows you to correctly assign all spark plug wires without a reference diagram.

A conventional contact-breaker (points) distributor also houses the points and condenser on the baseplate, which interrupt the primary coil circuit to induce the secondary high-voltage spike. An electronic distributor replaces the points with a magnetic pickup or Hall-effect sensor, which triggers an external ignition module. The wiring to the distributor body therefore differs: a points distributor has two terminals (primary feed and a side-contact connection to the coil negative); an electronic distributor adds two to four wires for the pickup sensor supply, signal, and ground.

Always disconnect the battery negative terminal before working on ignition system wiring. High-voltage ignition pulses can cause severe muscle-contraction shocks.

How to wire distributor diagram

Find top dead centre (TDC) on cylinder one compression stroke Remove the spark plug from cylinder one and place your thumb over the hole. Rotate the engine slowly (by hand at the crankshaft pulley bolt, or using a breaker bar) until you feel compression pressure at your thumb. Continue rotating until the timing mark on the crankshaft pulley aligns with the TDC mark on the timing cover. This confirms you are on the compression stroke of cylinder one, not the exhaust stroke.
Mark the number-one cap terminal position With the engine at TDC on cylinder one compression, look directly down at the distributor cap. Remove the cap and observe the rotor tip direction. Mark the corresponding position on the cap body (the terminal the rotor is pointing at) with a paint marker or tape — this is the number-one terminal. This step is critical before removing any plug leads.
Remove and label all spark plug leads before removal Before removing any spark plug lead from the distributor cap, label it with the cylinder number it serves. Use masking tape and a marker, or numbered cable ties. Photograph the cap from directly above. Removing leads without labelling them and attempting to rely on memory is the source of most distributor reassembly errors.
Determine rotor rotation direction Crank the engine briefly with the cap removed (do not allow the engine to start) and observe the direction the rotor turns when viewed from above. On most four-cylinder engines in common use the rotor turns clockwise, but this varies — confirm it for your specific application. Note the direction: you will assign plug leads in firing-order sequence following this direction.
Assign spark plug leads in firing order sequence Starting from the number-one terminal, assign leads to consecutive cap terminals in the direction of rotor rotation, following the engine's firing order. For a 1-3-4-2 firing order rotating clockwise: terminal 1 gets the lead from cylinder 1, the next clockwise terminal gets the lead from cylinder 3, the next gets cylinder 4, the next gets cylinder 2. Consult the engine's service manual for the specific firing order and the physical layout of cylinders.
Set base ignition timing with a timing light Connect a timing light to the number-one plug lead and to the vehicle battery. Locate the timing marks on the crankshaft pulley and timing cover — clean them and mark with chalk or white paint for visibility. Start the engine and aim the timing light at the timing marks. The mark on the pulley should align with the specified BTDC value (found in the vehicle service manual or emissions label). Loosen the distributor clamp bolt and rotate the distributor body to advance or retard timing as required.
Verify and lock down the distributor After setting timing, tighten the distributor clamp bolt to the specified torque. Re-verify timing with the light after tightening, as the clamp action can slightly rotate the distributor body. Reconnect all hoses and wiring that were disconnected for access. Test drive the engine under load — listen for detonation (pinging) on acceleration, which indicates timing is too far advanced.

Specifications

Distributor shaft speed relative to crankshaft	Half crankshaft speed on a four-stroke engine (camshaft speed)
Contact-breaker point gap (typical)	0.35 mm–0.50 mm (exact value per engine service manual)
Condenser capacitance (conventional distributor)	0.18 µF–0.25 µF
Spark plug lead suppression resistance	4 kΩ–10 kΩ per metre (suppressed type for EMI compliance)
Coil secondary voltage (typical petrol ignition)	20 kV–50 kV
Ignition timing base setting	Specified in degrees BTDC per engine service manual or emissions label

Safety warnings

Disconnect the battery negative terminal before handling distributor wiring, points, or condenser. Although the low-voltage primary circuit is 12 V, a shock from the primary winding can still be unpleasant and may startle a person into dropping tools or moving rapidly near a running engine.
Never touch spark plug leads or the coil high-voltage terminal while the engine is running. Secondary ignition voltages of 20 kV to 50 kV are present. At these voltages, even a brief contact through damp clothing can deliver a severe shock capable of causing involuntary muscle contraction. People with cardiac conditions or pacemakers must not work near running ignition systems.
Do not crank the engine with the distributor cap removed for more than a brief moment needed to observe rotor direction. Exposed rotating parts and the coil primary circuit present hazards. Keep hands and clothing clear of all moving components.
When setting timing with the engine running, keep all testing equipment leads, clothing, and body parts clear of the cooling fan, fan belt, and any other moving accessory drive components.

Tools needed

Timing light (inductive pickup clamp-on type)
Feeler gauge set (for contact-breaker point gap adjustment)
Digital multimeter with resistance and DC voltage modes
Distributor wrench or clamp bolt socket (application-specific)
Chalk or white paint marker (for highlighting timing marks)
Combination spanners or socket set
Masking tape and permanent marker (for labelling plug leads)
Workshop manual or service data for the specific engine (firing order, timing specification)

Common mistakes

Removing all spark plug leads simultaneously without labelling: reinstalling leads in the wrong order creates a sequence that may be one or two positions off, causing the engine to run very poorly or not at all. Label every lead before removing any of them.
Setting timing on the exhaust stroke of cylinder one instead of the compression stroke: if the engine is at TDC on the exhaust stroke, you are 360° crankshaft off. The plug lead assignment sequence around the cap will be offset by the same amount. Always confirm compression stroke by feeling pressure at the plug hole or by watching valve motion.
Replacing points without replacing the condenser: a worn condenser allows arcing across new points, which rapidly pits and oxidises the contact surfaces. The condenser is inexpensive — always replace it as a set with the points.
Over-lubricating the distributor shaft or cam: excess grease migrates onto the points contacts, causing high-resistance arcing and misfires. Use only a tiny amount of high-melting-point grease on the distributor cam lobes, with none on the contact faces.
Rotating the engine backwards to find TDC: always rotate the engine in its normal direction of rotation. Reversing the engine can disengage timing chains or belts on some engines and will give an incorrect timing mark alignment due to drive-train slack.

Troubleshooting

Engine cranks but will not start; no spark at any plug: Cause: Failed coil, open primary circuit, shorted condenser (on points-type distributor), or corroded distributor cap central contact Fix: With engine cranking, use a test light to verify 12 V is present at the coil positive terminal and pulses to ground at the coil negative (switching action from points or electronic module). If 12 V is constant at negative (no switching), the points, module, or pickup sensor has failed. Inspect the cap central carbon contact for wear or corrosion. Test coil primary and secondary resistance against specification.
Engine misfires on one cylinder consistently: Cause: Cracked or tracking distributor cap at one terminal, faulty spark plug lead on the affected cylinder, or loose/corroded terminal connection at cap or plug Fix: In a dark environment, run the engine and look for HV arcing from the exterior of the cap or along the spark plug lead. Remove the cap and inspect the affected terminal for carbon tracking (black line from terminal to a crack or to another terminal). Replace the cap if tracking is visible. Test the plug lead resistance — a cracked suppressor carbon track inside reads high or open circuit.
Engine detonates (pings) under load after timing adjustment: Cause: Base timing set too far advanced, vacuum advance unit faulty (delivering advance under heavy load when it should not), or fuel octane rating too low for the timing setting Fix: Retard base timing in 2° increments until detonation stops at the same operating conditions. Verify vacuum advance is connected to manifold vacuum (for OEM configuration) or ported vacuum (at the carburettor throttle plate) per the application's specification — the correct source depends on the emissions calibration of the vehicle.
Spark plug leads arc to each other or to the engine block: Cause: Deteriorated lead insulation, leads routed in contact with hot exhaust components, or excessive secondary voltage Fix: Replace the full set of spark plug leads with new suppressed leads rated for the coil's output voltage. Route leads in the OEM-specified separators or clips to keep them separated from each other and from exhaust manifold surfaces. Leads from adjacent cylinders with sequential or near-sequential firing order (e.g. 1 and 3 in a 1-3-4-2 order) should be physically separated to prevent cross-fire.

Frequently asked questions

How do I identify which cap terminal is for cylinder number one?

With the engine at top dead centre (TDC) on cylinder one's compression stroke, the rotor tip will be pointing at (or very close to) the cylinder-one terminal on the cap. Mark the cap at the rotor tip position — that is the number-one terminal. Alternatively, some distributors have a notch, arrow, or moulded number on the cap body indicating the number-one terminal position.

What is ignition timing and why does it matter?

Ignition timing is the crankshaft angle — measured in degrees before top dead centre (BTDC) — at which the spark fires in each cylinder. Too early (excessive advance) causes detonation (pinging) and engine damage. Too late (retarded) causes power loss, overheating, and fuel waste. Base timing is set mechanically by rotating the distributor body; additional advance is provided by the vacuum advance and centrifugal advance mechanisms inside the distributor, or by the engine management system on electronic ignitions.

How does the capacitor (condenser) in a points distributor work?

When the contact points open, the primary coil current collapses rapidly — this would cause the points to arc, eroding them quickly and reducing the sharpness of the current collapse (which reduces secondary voltage). The condenser, wired in parallel with the points, absorbs the inductive energy spike at the moment of opening. This suppresses arcing across the points and produces a sharper, faster current collapse in the primary winding, generating a higher secondary voltage.

What is the difference between vacuum advance and centrifugal advance in a distributor?

Centrifugal advance uses flyweights under the rotor plate that advance timing as engine speed increases — faster rotation requires the spark to fire earlier to allow full combustion before the piston passes TDC. Vacuum advance uses engine intake manifold vacuum to advance timing further at light throttle / low load conditions to improve fuel economy and emissions. Both mechanisms move the distributor rotor or baseplate relative to the shaft.

Why does spark plug lead order around the distributor cap matter?

Spark plug leads must be routed from the cap terminals to the correct plugs in the engine's firing order sequence, arranged in the direction of rotor rotation. If a lead is placed on the wrong terminal (even by one position), that cylinder fires at the wrong time, causing misfires, backfiring, loss of power, and potential catalytic converter damage.
