Android Head Unit Wiring Diagram: Standard ISO Harness Connections
This is a free printable android head unit wiring diagram: download the diagram as SVG or open it and print to paper or PDF.
An android head unit wiring diagram shows how to connect an aftermarket double-DIN Android car stereo to a vehicle's electrical system using the standard ISO 10487 connector harness — covering power, ground, ignition, speakers, and accessories.
Android-based car head units are aftermarket double-DIN (180 mm × 100 mm) or single-DIN automotive media systems running the Android operating system, offering GPS navigation, application support, Bluetooth, Wi-Fi, and multimedia playback. Despite the variety of manufacturers and screen sizes, the electrical connections follow the universal ISO 10487 standard (commonly called 'ISO harness' or 'ISO connector'), which defines a pair of 8-pin connectors: ISO-A for power and ground, and ISO-B for speaker outputs.
ISO-A connector — power: Pin A1 (yellow wire): permanent 12 V DC supply, directly from the battery via a fuse. This powers the head unit's memory functions (clock, station presets, settings) even with the ignition off. It must be fused, typically at 10–15 A. Pin A4 (ground, black wire): chassis ground. A good, low-resistance earth connection is essential; a poor ground causes audio noise, display flicker, and erratic behaviour. Pin A5 (blue/white wire): amplifier remote turn-on output. This outputs 12 V when the unit is on, used to trigger an external amplifier's remote input or a relay. Pin A7 (red wire): ignition-switched 12 V (also called the accessory or ACC supply). The head unit powers on when this line goes live and powers off when the ignition is off. Connecting this to permanent 12 V instead will cause the unit to stay on with the ignition off, draining the battery. Pin A8 (yellow wire — some implementations): second permanent 12 V (varies by manufacturer; always check the specific harness adapter documentation).
ISO-B connector — speakers: The speaker outputs are low-level (from the internal amplifier, not pre-amplified line level). Standard configurations provide four channels: front left, front right, rear left, rear right. Each channel has a positive (+) and negative (−) output. Speaker wire on the ISO-B connector must not be earthed to chassis — the head unit uses a bridged (BTL) amplifier design where neither speaker terminal is at zero volts. Grounding a speaker output to chassis will blow the amplifier output stage.
Vehicle-specific harness adapters (ISO to OEM connector) are available for most vehicle models, allowing a plug-and-play connection without cutting original wiring. The head unit's ISO pigtail connects to the adapter, which plugs into the vehicle's factory connector.
How to wire android head unit wiring diagram
- Disconnect the vehicle battery before starting Remove the negative battery terminal (black cable) first, then the positive. Wait at least 60 seconds for any capacitors in the vehicle's electronics to discharge. This prevents short circuits, protects vehicle control modules, and eliminates the risk of electric shock during wiring work.
- Identify and obtain the correct vehicle harness adapter Look up your vehicle's make, model, and year to find the correct ISO harness adapter. The adapter converts the vehicle's OEM multi-pin connector to the standard ISO-A and ISO-B format. Verify the adapter handles steering wheel control (SWC) integration if your vehicle has factory steering wheel audio controls — a separate SWC interface module is typically required.
- Prepare the head unit ISO pigtail wiring Most Android head units are supplied with an ISO pigtail harness. Verify the colour coding against the documentation supplied with the unit — do not assume a universal colour standard across all manufacturers. Common convention: yellow = constant 12 V, red = switched 12 V, black = ground, blue or blue/white = amplifier remote. Terminate bare wire ends with crimp connectors or solder and heat-shrink; do not use insulation tape alone.
- Connect the power and ground wires Connect the yellow wire (constant 12 V) to a permanently live, fused supply in the vehicle — typically via the existing fuse box or a new inline fuse holder wired directly to the battery positive terminal via an appropriate fuse (10–15 A). Connect the red wire (switched 12 V) to the ignition-switched supply, which can be tapped from the factory harness adapter. Connect the black wire to a known-good chassis earth point — a dedicated bolt on the vehicle bodywork, not a painted surface.
- Connect the speaker wires Match the head unit's speaker output wires to the vehicle's factory speaker wiring via the harness adapter. Standard ISO-B colour conventions are: front left positive/negative (white+/−), front right (grey+/−), rear left (green+/−), rear right (violet/purple+/−). Verify against the vehicle adapter documentation. Never connect a speaker output to chassis ground.
- Connect the GPS antenna, microphone, and accessory leads Route the GPS antenna lead to a clear-sky location on the dashboard and connect it to the GPS antenna port. Connect the external microphone (if supplied) to the microphone port and position it at the driver's A-pillar or sun visor area. Connect the parking brake wire (typically yellow with black stripe, labelled 'BRAKE' or 'P-BRAKE') to the vehicle's handbrake sensor wire or to chassis ground if menu access in motion is not required.
- Reconnect the battery and test before final installation Reconnect the negative battery terminal. Turn the ignition to the accessory position and verify the head unit powers on, audio plays through all four speakers, GPS acquires a fix, and Bluetooth connects. Test all functions before sliding the unit into the dash pocket. This saves dismantling the dash again to correct a wiring error.
Specifications
| Standard form factor | Double-DIN: 180 mm wide × 100 mm tall (ISO 7736) |
|---|---|
| Constant 12V supply (yellow wire, ISO-A pin A1) | 12 V DC permanent; fused at 10–15 A |
| Ignition-switched supply (red wire, ISO-A pin A7) | 12 V DC, live with ignition on or in accessory position |
| Ground (black wire, ISO-A pin A4) | Chassis ground; 0 V reference |
| Amplifier remote (blue/white wire, ISO-A pin A5) | 12 V DC output when unit is on; typically rated 200–500 mA |
| Speaker output impedance (internal amp) | 4 Ω nominal load; outputs typically 20–55 W RMS per channel depending on model |
| GPS antenna type | Active GPS antenna; typically powered at 3.3 V or 5 V via antenna port |
| ISO connector standard | ISO 10487 (automotive audio connector: ISO-A power + ISO-B speaker) |
Safety warnings
- Always disconnect the vehicle's negative battery terminal before working on any vehicle wiring. Failure to do so risks short circuits that can damage expensive control modules, trigger airbag deployment, or cause fire in wiring harnesses.
- The constant 12 V (yellow) supply wire must be individually fused as close to the battery positive terminal as possible. This wire runs through areas of the vehicle that are not protected by the factory fuse box. An unfused 12 V wire can start a fire if it chafes against metalwork.
- Never touch the airbag system wiring, which is typically yellow or yellow-striped. Airbag control module wiring can inadvertently deploy an airbag if disturbed, causing serious injury.
- On vehicles with a factory amplifier (where the head unit's speaker outputs go to an amplifier module rather than directly to speakers), do not use a standard ISO speaker harness adapter without an amplifier retention module. Doing so bypasses the factory amplifier and leaves the speakers with a very weak signal or potentially damages the factory audio system.
Tools needed
- Panel removal tools (plastic trim pry tools, non-marring)
- Wire stripper
- Crimping tool and heat-shrink crimp connectors
- Multimeter (DC voltage measurement)
- Electrical tape or split-loom conduit for wire management
- Screwdrivers (flat and Pozidriv/Phillips, varies by vehicle)
- Test light (12 V) for locating ignition-switched and permanent supplies
Common mistakes
- Connecting the red (switched 12V) wire to a permanent supply: the unit stays on after the ignition is off, draining the battery overnight.
- Connecting a speaker output to chassis ground: destroys the head unit's internal amplifier output stage, usually immediately.
- Running the GPS antenna cable bundled with power cables: RF interference from the power wiring reduces GPS sensitivity. Route the GPS antenna lead separately, away from power wiring.
- Choosing the wrong harness adapter for the vehicle model year: adapter pinouts can differ between model years even for the same vehicle nameplate. Always verify adapter compatibility for the specific year.
- Not addressing the factory amplifier: many vehicles from 2005 onward have a separate factory DSP or amplifier. Ignoring this produces very low volume or distorted audio from the aftermarket head unit.
Troubleshooting
- Head unit powers on but audio from speakers is very weak or distorted
- Cause: Vehicle has a factory-fitted amplifier that is not being driven correctly by the aftermarket head unit's speaker-level outputs Fix: Research whether the vehicle has a factory amplifier. If it does, obtain a suitable amplifier retention interface or line output converter. Alternatively, connect the head unit's RCA pre-amp outputs to a compatible aftermarket amplifier.
- Head unit loses all settings and clock every time the ignition is turned off
- Cause: Yellow (constant 12V) wire is connected to an ignition-switched supply rather than a permanent supply Fix: Trace the yellow wire connection. Use a multimeter to verify it shows 12 V with the ignition off. If voltage drops to zero with ignition off, re-route it to a permanently live fused supply.
- GPS never acquires a fix or takes more than 15 minutes
- Cause: GPS antenna positioned with no clear sky view (under metal dash top); antenna cable too close to interference sources; antenna connector not fully seated Fix: Reposition the GPS antenna higher on the dashboard, as close to the windscreen as possible with the antenna face pointing upward. Verify the antenna connector is fully engaged at the head unit. Run the antenna lead away from power cables.
- Constant whine or buzzing from speakers that changes pitch with engine speed
- Cause: Alternator noise induced through a poor chassis ground connection for the head unit Fix: Improve the head unit ground by running a dedicated earth wire from the head unit's ground terminal directly to a clean metal chassis point. If the problem persists, install a ground loop isolator on the audio output or use a ferrite bead on the power supply leads.
Frequently asked questions
What is the difference between the yellow (constant 12V) and red (switched 12V) wires on a head unit harness?
The yellow wire is permanent 12 V direct from the battery, always live regardless of ignition position. It powers the head unit's memory (clock, settings, presets). The red wire is ignition-switched 12 V, only live when the ignition is on or in the accessory position. The red wire controls when the unit turns on and off. Swapping them causes battery drain or loss of settings.
Why must Android head unit speaker outputs not be grounded to chassis?
Most aftermarket head unit amplifiers use a bridged (BTL) output topology: neither the positive nor the negative speaker terminal is at 0 V (chassis potential). Both terminals swing relative to a mid-rail reference. Connecting either speaker terminal to chassis creates a short circuit across half the output stage, immediately damaging or destroying the amplifier IC.
What is the blue/white wire on an aftermarket head unit?
The blue/white wire (sometimes called the remote, amp remote, or aerial amplifier turn-on wire) outputs 12 V when the head unit is powered on. It is used to trigger the remote input of an external amplifier, switching the amplifier on in synchronisation with the head unit. It is also used to power an electric aerial motor on vehicles with a motorised antenna.
Do I need a vehicle-specific harness adapter or can I wire directly?
A vehicle-specific harness adapter is strongly recommended. It allows the head unit to plug into the vehicle's factory wiring without cutting or splicing original wires, preserving the option to restore the factory stereo. Cutting original wiring degrades the vehicle's resale value and risks wiring errors. Adapters are widely available for most vehicle makes and models.
My new Android head unit has a GPS antenna connection. Where does it go?
The GPS antenna is a small active antenna (typically on a 3–5 metre lead) that must be placed with a clear view of the sky, usually on the dashboard near the windscreen or inside the top of the dashboard. It connects to the head unit's GPS antenna input (SMA or FAKRA connector depending on the unit). A poor antenna location is the most common cause of slow GPS acquisition.
