3 phase compressor wiring diagram
This is a free printable 3 phase compressor wiring diagram: download the diagram as SVG or open it and print to paper or PDF.
A three-phase compressor wiring diagram shows how to safely connect industrial air compressors powered by three-phase electric service (208V, 240V, 277V, or 480V depending on facility). The diagram identifies: three phase conductors (U, V, W), neutral conductor (if 208V four-wire service), ground conductor, and motor control devices protecting the compressor motor from damage. Three-phase motors provide 15-50% greater efficiency than single-phase motors of equivalent horsepower, making three-phase essential for industrial compressed air systems requiring continuous operation. The diagram shows: motor disconnect switch isolating all power during maintenance, three overload relays (one per phase) protecting motor windings from phase imbalance or thermal stress, and a start/stop control circuit enabling operator control. Starting methods include: across-the-line starting (simplest, causing high inrush current), star-delta soft-start (reducing inrush to 25% of across-the-line), or VFD (Variable Frequency Drive) enabling energy-efficient part-load operation. Modern compressor diagrams include: compressor unload valve reducing motor load during idle periods, pressure switch controlling start/stop cycle, and electric-heated aftercooler drying compressed air.
How to wire 3 phase compressor wiring diagram
- Confirm supply voltage and phase rotation before wiring Test incoming supply with a phase rotation meter. Confirm 380V between phases and 220V phase to neutral. Record phase rotation (ABC or ACB) — you will need this to wire the motor correctly.
- Wire the main isolator and MCCB Run supply from the distribution board through a lockable isolator, then through the 3-pole MCCB. Size MCCB to 125% of motor FLA. Ensure the isolator is accessible for emergency shutdown.
- Wire the contactor main contacts Connect L1, L2, L3 from MCCB output to contactor input terminals. Wire contactor output terminals to the thermal overload relay input. Wire overload output to compressor motor terminals T1, T2, T3.
- Install and wire the control transformer Wire control transformer primary to L1 and L2 of the incoming supply. Connect secondary output to the control circuit fuse, then to the common rail of the control circuit.
- Wire the pressure switch to the contactor coil Connect 220V from the control circuit through the pressure switch NO contacts to the contactor coil A1 terminal. Connect A2 to the control neutral. Pressure switch closes when pressure drops to cut-in, energising the coil.
- Wire the overload relay trip contact in series Insert the overload relay NC contact in series between the control supply and the contactor coil. If the overload trips, this contact opens and drops the contactor, stopping the motor immediately.
- Test phase rotation and motor direction on first start With all wiring complete, briefly energise and observe motor rotation direction. The correct direction is typically marked on the compressor head. If backwards, swap any two phase connections at the motor terminals — not at the supply.
Frequently asked questions
Why does my 3-phase compressor motor run hot even though the overload is not tripping?
Check for phase imbalance — measure current on all three phases. If one phase is significantly higher than the others, you have a voltage imbalance at the supply. Even a 2% voltage imbalance causes 6–10% current imbalance, generating excess heat without tripping the overload relay.
Can I connect a 3-phase compressor to any phase order?
No. 3-phase motors are direction-sensitive. Wrong phase sequence runs the motor backwards, compressing against the check valve and either stalling or running without building pressure. Always fit a phase rotation relay and check rotation direction on first start by briefly energising and watching the motor shaft.
When do I need a star-delta starter versus direct-on-line?
Use star-delta for compressor motors 7.5kW and above, or where your supply authority imposes a maximum starting current demand. Star-delta reduces starting current to approximately one-third of DOL starting current. Confirm with your electrician whether your supply point can handle DOL starting before deciding.
My 3-phase compressor trips the overload relay only on hot restarts. Why?
The motor windings are already hot from the previous run, reducing their impedance and allowing higher current on restart. Check that the unloader valve is fully releasing head pressure before restart — a compressor restarting against head pressure draws much higher current than an unloaded restart.
How do I set the overload relay correctly?
Set the overload relay dial to the motor nameplate full-load ampere (FLA) rating — not the breaker rating. Run the compressor at full load and verify actual current with a clamp meter. If measured current is consistently below FLA, you may fine-tune the setting down slightly to improve protection sensitivity.
